Запчасти Case IH 1440 (21-16) - THRESHING ROTOR AND CONCAVES, CONE, S/N 1501 AND ABOVE (14) - THRESHING

1

454502R1

LATCH

separator front door

2шт.

648002

KNIFE

1/8" x 3/4"

1шт.

120394

WASHER,3/8", SAE

WASHER, .406 x .812 x .051

1шт.

2

M296

SPRING

front door latch

2шт.

3

193436C2

DOOR

separator front

1шт.

4

160638C1

HANDLE

rotor front door

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

135270

SERRATED SCREW,5/16" - 18 x 3/4"

5/16 x 3/4 znp slt-truss-hd

1шт.

5

182975C93

DOOR

rotor front, Serial Range: 1501-10000

1шт.

5

1300208C91

DOOR

rotor front, includes ref no. 10, Start Serial: 10001

1шт.

135270

SERRATED SCREW,5/16" - 18 x 3/4"

5/16 x 3/4 znp slt-truss-hd

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

6

168481C1

LATCH ASSY.

LATCH, rotor front door, Serial Range: 1501-10000

2шт.

436734

SCREW,Slotted Pan Hd, #10-24 x 3/4"

no. 10 x 3/4 znp p/hds mach

1шт.

120361

NUT,Hex Mach Screw, #10 - 24

1шт.

7

1317770C2

CONE

ASSY, transition, grain, replaces 1309419C2, also order 186985C3, vane cone short, Serial Range: 1501-10000

1шт.

154273C1

BOLT,Hex Serr, 3/8" - 16 x 1", Spcl

SCREW, 3/8-16 x 1 lock

1шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8 flange lock

1шт.

8

195202C1

SEAL

feeder

2шт.

9

195409C1

PLATE

seal back up

2шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

10

179749C2

PRODUCT GRAPHIC

danger

1шт.

11

1302141C2

SUPPORT

LH pocket, used with cone assy 1309419C2, not used anymore

1шт.

154273C1

BOLT,Hex Serr, 3/8" - 16 x 1", Spcl

SCREW, 3/8-16 x 1 lock

1шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8 flange lock

1шт.

12

120253C1

CONDUIT

LH pocket support, 8.25 in.

1шт.
