Запчасти Case IH 1420 (10-42) - HYDRAULICS, HYDRAULIC REEL DRIVE, WITH TRAP AND, OR FEEDER REVERSER, SEPERATOR PARTS (07) - HYDRAULICS
№
Артикул
Название
Примечание
Количество
1
1320206C2
PULLEY
ASSY, drive
1шт.
2
183739C2
SHIELD
reel drive pump, Includes: screw and nut
1шт.
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
5/16 x 1/2 slt-truss-hd
1шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16 flange lock
1шт.
3
187875C1
SUPPORT
reel drive pump,w/o feeder reverser to 20000
1шт.
3
1317948C1
SUPPORT
reel drive pump, w/o feeder reverser, Start Serial: 20001
1шт.
1322688C1
SUPPORT
reel drive pump, w/feeder reverser, Includes: screw and nut
1шт.
154273C1
BOLT,Hex Serr, 3/8" - 16 x 1", Spcl
SCREW, 3/8 x 1 lock
1шт.
482256R1
BEARING LOCK NUT,Flg, USR, 3/8"-16
3/8 flange lock
1шт.
4
PUMP ASSY, reel drive, for details refer to this group under reel drive pump, Ross or Cessna, Includes: bolt and nut
1шт.
180124
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
3/8 x 1-1/4 type 5
1шт.
482256R1
BEARING LOCK NUT,Flg, USR, 3/8"-16
3/8 flange lock
1шт.
5
193252C1
PULLEY
ASSY, pump driven, 7.5" O.D., 7/8" I.D.
1шт.
1330177C2, pulley is 5" o.d. bj 2-6-98
1шт.
128228
SET SCREW,Sq Hd, 3/8"-16 x 3/4"
SCREW, 3/8 x 3/4 znp sq/hd c/pt set
1шт.
124829
JAM NUT,Hex, 3/8" - 16, Gr 5
1шт.
6
1320608C91
SHIELD
ASSY, drive, inc. ref. no. 9, Includes: screw, nut and bolt
1шт.
174985C1
BOLT,Hex Serr, 1/2" - 13 x 1"
SCREW, 1/2-13 x 1 hex flange
1шт.
487374R1
BEARING LOCK NUT,Flg, USR, 1/2"-13
1/2 hex flange
1шт.
540858R1
BOLT,Hex Serr, 1/2" - 13 x 1 1/2"
1/2 x 1-1/2 hex-hd flange
1шт.
7
189466C1
SUPPORT
BRACKET, shield support, Includes: screrw and nut
1шт.
135270
SERRATED SCREW,5/16" - 18 x 3/4"
5/16 x 3/4 znp slt-truss-hd
1шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16 flange lock
1шт.
1315315C1
V-BELT,22.33mm W x 1868.69mm L
Reel Pump Drive, with Feeder Reverser 22.33 mm W x 1868.69 mm L
1шт.
9
1320694C1
DECAL
PRODUCT GRAPHIC, danger
1шт.
Выбрано товаров: 26
