Запчасти Case IH 47 (A-10) - HOPPER

1

458850R91

CHAIN ASSEMBLY, hopper

2шт.

2

457095R1

S-HOOK, hopper chain

2шт.

3

459510R91

SIDE ASSEMBLY, left hopper

1шт.

31715H

RIVET, 9/64 x 1/4 slt tub

6шт.

112470

WASHER, 5/32 x 3/8 x 18 B.W. ga

6шт.

4

458847R1

SUPPORT, hopper strip

4шт.

120375

NUT,Hex, 1/4" - 20, Gr 5

24шт.

120583

SCREW,Sl Rnd Hd, 1/4" - 20 x 5/8"

1/4-20 x 5/8 C-Z slt-hd

24шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

24шт.

5

458849R1

ROD, chain tie

1шт.

103384

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

2шт.

Q1597

WASHER

13/32 x 3/4 x 16 ga flat

2шт.

6

458844R21

SHEET ASSY, front hopper

1шт.

7

459511R91

SIDE ASSEMBLY, right hopper, furnish 459510R91 for 459511R9

1шт.

31715H

RIVET, 9/64 x 1/4 slt tub

6шт.

112470

WASHER, 5/32 x 3/8 x 18 B.W. ga

6шт.

8

458848R1

ROD, pivot

1шт.

648002

KNIFE

1/8" x 3/4"

2шт.

611346R1

WASHER

13/32 x 3/4 x 16 ga C-Z

4шт.

9

471130R1

CLIP, spring

2шт.

19428R1

BOLT, 5/16-18 x 5/8 C-Z short-sq-nk crg

1шт.

120376

NUT,5/16"-18, G5

1шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

10

13320S

SPRING

1шт.
