Запчасти Case IH 45 (A-19) - WAGON UNLOADING ATTACHMENT, 45 BLOWER, RATCHET WHEEL

1

459386R1

GRIP, handle

1шт.

2

458830R1

HANDLE, control

1шт.

3

458827R11

INDEX ASSEMBLY

1шт.

512166R1

PIN,1/4" x 7/8"

1/4 x 7/8 headed dld

1шт.

1089630

PIN, 1/8 x 7/8 cot.

1шт.

990325R91

RIVET

1/4 x 1 button-hd, 1 lb pkg

3шт.

4

458821R1

ARM, inner cam follower

1шт.

LC175

PIN

1/2 x 2-1/2 hd-dld

1шт.

Q839

SPLIT PIN/SAFETY PIN

PIN, 3/4 x 2-5/8 hd-dld

1шт.

432-1624

COTTER PIN,1/4" x 1 1/2"

Pin, Split (Cotter), 1/4" x 1 1/2"

1шт.

432-1216

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

1шт.

5

458814R1

PIN, roller

1шт.

102639

NUT,5/8"-11, G5

1шт.

103325

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

6

332040

LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg

FITTING, 1/8 pt 90 deg lub

1шт.

7

458803R1

RETAINER, coil spring

1шт.

17426R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1 hex-hd mach

4шт.

102635

NUT,3/8"-16, G5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

8

452696R1

EYEBOLT, coil spring retainer

1шт.

102635

NUT,3/8"-16, G5

2шт.

9

R13109

SPRING, extension

1шт.

10

359141R1

RING, SNAP

RING, ratchet wheel shaft snap

1шт.

11

551769R1

WASHER

1-13/32 x 2 x 16 ga plain

6шт.

12

332040

LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg

FITTING, 1/8 pt 90 deg lub

2шт.

13

458808R11

BOX W/BUSHINGS ASSY, ratchet wheel bearing

2шт.

14

458807R1

SHAFT, ratchet wheel

1шт.

20341R1

COTTER PIN,1/4" x 2"

Pin, Split (Cotter), 1/4" x 2"

1шт.

117991

WOODRUFF KEY,#D, 5/16" x 1 1/4", HT

1шт.

15

458810R1

RATCHET, wheel

1шт.

16

458804R1

SPRING, front pawl

1шт.

17

458823R1

PAWL, ratchet

2шт.

18

458825R1

CLEVIS, coil spring

1шт.

19

458815R11

ROLLER W/BUSHINGS ASSEMBLY

1шт.

20

458822R1

ARM, outer cam follower

1шт.

21

458806R1

SPACER, pipe

2шт.

22

458805R1

SPRING, rear pawl

1шт.

23

458802R1

SHAFT, pawl retarder

1шт.

102637

NUT,1/2"-13, G5

2шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.
