Запчасти Case IH 8790 (178) - BRAKE SYSTEM, PARKING BRAKE (33) - BRAKES & CONTROLS

10

36252911

LEVER GUIDE

console

1шт.

11

36252928

RETAINER

support

1шт.

12

03126906

ACCUMULATOR

spring accumulator FS40-13S

1шт.

14

614-12030

BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd

4шт.

15

100038

NUT,M12 x 1.75, Cl 8

4шт.

16

36206996

HEAD

yoke

1шт.

17

825-11416

NUT,M16 x 1.5, Cl 8

ISO 8673

1шт.

19

733-3220

COTTER PIN,M3.2 x 20

1шт.

20

36416056

LARGE PIN

PIN, LARGE

1шт.

30

86500689

NUT,M10 x 1.5, Cl 10

2шт.

31

814-10050

BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8

2шт.

32

36415690

SHIN

STRAP

2шт.

33

36415705

PLATE

SPACER

2шт.

18

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

2шт.
