Запчасти Case IH 8790 (060A) - RADIATOR SYSTEM, RADIATOR FRAME (10) - ENGINE

1

36416103

BAR

BRACKET

1шт.

2

36416111

HOSE,8.00 mm ID x 62.00

1шт.

3

36416128

HOLDER

SUPPORT

1шт.

4

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

1шт.

5

06400954

PIN, SPLIT (COTTER)

PIN, COTTER splint, 2 x 16 DIN94 ST

1шт.

6

614-8016

BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd

1шт.

7

829-4408

NUT,Thin, M8 x 1.25, Cl 05

Hex, IS0 4035

2шт.

8

06577028

SPECIAL WASHER

M8

2шт.

9

07081255

CABLE TIE

CABLE STRAP PMCC38-H25

2шт.

12

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

1шт.
