1
84140384
FILTER HEAD
Fuel
1шт.
2
J906694
SEALING RING,Square, 1.68mm Thk x 69.57mm ID, -39
70mm ID
1шт.
3
J906695
SEAL,Square, 0.103" Thk x 0.549" ID, -113
Fuel Filter Stud O-Ring
1шт.
4
J903293AM
NUT
Hex Nut, 16mm
1шт.
5
J925955
ADAPTER,M16 x 1.5 x M16 x 1.5
Fuel Filter
1шт.
6
84476807
FUEL FILTER
Primary
1шт.
7
84557099
FUEL FILTER
Secondary
1шт.
8
84142216
FUEL PUMP
Lift
1шт.
9
J939258
GASKET,1.21mm Thk
Pump Mounting
1шт.
10
86511479
BOLT,Hex Flg, M8 x 20mm
2шт.
11
J907582
FUEL TUBE,8 mm OD x 250.6 mm L
Supply
1шт.
12
J903035
BANJO BOLT
Hex, 12mm x 1.5 x 24mm
1шт.
13
87415913
SEALING WASHER,11.71mm ID x 19.3mm OD x 1.27mm Thk
12mm x 18mm x 1mm
2шт.
14
J918640
FUEL TUBE
Supply
1шт.
15
D139225
FILTER, FUEL
Inline
1шт.
16
J939570AM
CAPTIVE WASHER SCREW
Captive Vent Screw
1шт.
17
J911446
BANJO BOLT,M12 x 1.5 x 24mm
1шт.
18
86509027
FITTING,3/8" Hose x 1/4" NPTF, Barbed
1шт.
19
1348264C1
HOSE CLAMP
3/8"
2шт.
20
1348239C1
FUEL HOSE,9.52 mm ID x 78.00 mm, SAE 30R7
1шт.
