Запчасти Case IH P170 (0.32.3[01]) - PIPING - ENGINE COOLING SYSTEM (02) - ENGINE

1

4895538

FLANGE BOLT,Hex, M10 x 1.5 x 120mm

2шт.

2

4895292

FLANGE BOLT,Hex, M10 x 1.5 x 70mm

1шт.

3

2854072

SEALING RING,Square, 5.16mm Thk x 50.17mm ID

1шт.

4

2853125

HOUSING

- Assy, Incl. 5 -7

1шт.

5

2853126

1шт.

6

2853127

PLUG,1/2"-14 NPTF

1шт.

7

2853128

DOWEL,M6.35 x 19 L

2шт.

8

4895392

HEX SOCKET PLUG,M18 x 1.5

1шт.

9

4895393

O-RING,2.2mm Thk x 15.3mm ID

1шт.

10

4895623

HEX SOCKET PLUG,M16 x 1.5

- Assy, Incl. 11 - 12

1шт.

11

4895625

O-RING,13.3mm ID x 2.2mm Width

1шт.

12

4895624

PLUG,M16 x 1.5 x 18mm L

1шт.
