Запчасти Case IH P140 (10.105.01) - CONNECTING ROD (10) - ENGINE

Схема запчастей Case IH P140 - (10.105.01) - CONNECTING ROD (10) - ENGINE
6
5
4
2
1
3
10.103.01
10.105.02

Артикул

Название

Примечание

Количество

1

2831298

CONNECTING ROD

- ASSY, Inc. 2 -5

6шт.

2831298R

REMAN-CONNECTING ROD

P140 Irrigation Power Unit Tier 3 (10/09),

6шт.

2831298C

CORE-ROD CONNECTING

Return Number

1шт.

2

2831297

FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9

2шт.

3

NSS

NOT SOLD SEPARAT

ROD, Connecting, Inc. 4, 5

1шт.

4

4892708

BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L

1шт.

5

NSS

NOT SOLD SEPARAT

ROD, Connecting

1шт.

6

2856309

CRANKSHAFT BEARING

6шт.

6

4892715

BEARING LINER

BEARING, CON. ROD

6шт.

Выбрано товаров: 9
