Запчасти Case IH P110 (04-03) - OIL, LEVEL SHUTDOWN (04) - ELECTRICAL SYSTEMS

Схема запчастей Case IH P110 - (04-03) - OIL, LEVEL SHUTDOWN (04) - ELECTRICAL SYSTEMS
10
6
9
12
19
25
11
13
29
21
2
27
4
21
18
22
3
28
23
1
21
19
7
10
26
12
16
22
14
20
30
5
15
8
24
17
7

Артикул

Название

Примечание

Количество

1

1347701C1

SWITCH ASSY

Oil Level, High/Low, Incl 2 - 4

1шт.

2

251203A1

MOUNT

Rubber, Shock

4шт.

3

492-11025

LOCK WASHER,1/4"

4шт.

4

425-104

NUT,1/4"-20, Cl 5

4шт.

5

1347702C1

BRACKET

Mounting, Switch

1шт.

6

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

1шт.

7

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

2шт.

8

492-11038

LOCK WASHER,3/8"

1шт.

9

425-106

NUT,3/8"-16, Cl 5

1шт.

10

87575678

HYD CONNECTOR

2шт.

11

706670C1

HOSE

1шт.

12

1348264C1

HOSE CLAMP

2шт.

13

73200C1

HOSE,16mm ID x 1219.2mm L

1шт.

14

87448292

WIRE HARNESS

Oil Level

1шт.

15

87448295

END FITTING

Straight, 5/8 Stem End x 3/4 - 16

1шт.

16

217-1072

HYD CONNECTOR,1/2" - 14 NPTF

1шт.

17

217-1103

HYD CONNECTOR,1/2" - 14 NPT x 1/2" - 14 NPT

1шт.

18

217-134

ELBOW,90 Degree Elbow, 5/8" Hose Barb x 1/2" Male NPTF

1шт.

19

9706921

HOSE CLAMP,12.7mm - 35mm

2шт.

20

NSS

NOT SOLD SEPARAT

Hose Assy, Drain

1шт.

21

J902425

SEALING WASHER,22.2mm ID x 26.9mm OD x 1.75mm Thk

2шт.

22

87444972

BANJO BOLT

1шт.

23

87444970

HOSE ASSY.,12.7mm ID x 406.4mm L

Oil Drain

1шт.

24

218-625

TEE,3/4"-16, 37 Degree x 1/2"-14, NPTF Run

1шт.

25

262159

CAP,3/4" - 16 Fem JIC

1шт.

26

87444971

CHECK VALVE

1шт.

27

86637723

PLUG,Hex Hd, 1/2"-14 NPTF

1шт.

28

87444973

END FITTING

1шт.

29

87708245

SERVICE KIT

Low Oil Shut Down, Incl 1 - 20

1шт.

30

87455568

REPAIR KIT

Incl (1) Bezel, (1) Glass, (2) Gaskets and (8) Screws

1шт.

Выбрано товаров: 30
