Запчасти Case IH LE (62) - FAN AND WATER PUMP, V BELT DRIVE, ENGINE NUMBER LE300723 AND AFTER

B4467A

BODY, water pump. Use A130AA

1шт.

C4468A

IMPELLER, water pump (YR. 1934)

1шт.

B4779A

PULLEY, fan drive, lower. Use A921AA

1шт.

C4779A

PULLEY, fan drive, lower. Use A921AA

1шт.

A4875A

X

BUSHING, water pump (YR. 1934)

1шт.

A4877A

HUB, fan, with stationary half of pulley (YR. 1934)

1шт.

4878A

PULLEY, fan, adjustable half (YR. 1934)

1шт.

SCREW, 3/8" x 7/8" hexagon head cap, N.C. thread

1шт.

WASHER, 3/8" standard lock

1шт.

O1196AB2

RETAINER, fan bearing felt (YR. 1934)

1шт.

SCREW, 1/4" x 1/2" round head machine, N.C. thread

3шт.

WASHER, 1/4" standard lock

3шт.

O1197AB2

WASHER, felt, fan bearing (YR. 1934)

1шт.

O1198AB2

X

RETAINER, fan bearing (YR. 1934)

1шт.

O1204AB3

SHAFT, fan and water pump (YR. 1934)

1шт.

NUT, 5/8" hexagon, N.F. thread

1шт.

O1205AB1

X

GASKET, water pump (YR. 1934)

1шт.

O1539AB

FAN BLADE ASSEMBLY (18"-6 blade) See O5633AB or 2395AA (YR. 34-40)

1шт.

SCREW, 3/8" x 3/4" hexagon head cap, N.C. thread

4шт.

WASHER, 3/8" standard lock

4шт.

O2696AB1

X

BELT, fan (YR. 1934)

1шт.

O3152AB1

X

PIN, water pump impeller (YR. 1934)

1шт.

O3153AB

X

WASHER, thrust, water pump (YR. 1934)

1шт.

O3154AB

X

SPRING, water pump (YR. 1934)

1шт.

O3155AB

X

LOCK, water pump shaft nut (YR. 1934)

1шт.

O3157AB

X

BEARING, water pump and fan shaft, New Departure no. 7304 (YR. 1934)

1шт.

O3223AB

SCREW, set, fan pulley (YR. 1934)

1шт.

NUT, 1/2" hexagon, jam, N.C. thread

1шт.

O3288AB

FLANGE, fan drive pulley, for 921AA pulley (YR. 34-38)

2шт.

RIVET, 5/16" x 3/4" round head

10шт.

O5633AB

FAN BLADE ASSEMBLY (20"-6 blade) See O1539AB or 2395AA (YR. 1940)

1шт.

SCREW, 3/8" x 1" hexagon head cap, N.C. thread

4шт.

WASHER, 3/8" standard lock

4шт.

O6073AB

X

KEY, water pump and fan shaft (YR. 1934)

1шт.

A130AA

BODY, water pump, with bushing (YR. 1934)

1шт.

CUP, 1/2 ounce 1/8" male grease

1шт.

SCREW, 1/2" x 1" hexagon head cap, N.C. thread

3шт.

WASHER, 1/2" standard lock

3шт.

921AA

PULLEY, drive, with hub and flange. Use A921AA

1шт.

A921AA

PULLEY, drive, with hub, set screw and nut (YR. 1934)

1шт.

1211AA

WATER PUMP ASSEMBLY, less fan blades, lower fan pulley and belt (YR. 1934)

1шт.

2395AA

PARTS NECESSARY TO INSTALL O5633AB 20" FAN IN PLACE OF O1539AB 18" FAN (YR. 1934), Consists of 1 - O5633AB fan, 1 - A14AA fan housing and 1 - O2801AB1 fan housing bottom shroud.

1шт.
