Запчасти Case IH A284 (54) - INSTRUMENT PANEL, TYPE ONE DIESEL UNITS / TYPE ONE SPARK IGNITION UNITS

1

A11183

PANEL - instrument, Type 1 diesel units

1шт.

2

A11186

SHROUD - instrument panel

1шт.

187-986

SCREW - self tap, #10 x 1/2" hex. hd.

6шт.

3

O8066AB

SPACER - instrument panel

4шт.

13-840

BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5

- 1/2" x 2-1/2" N.C., hex.

2шт.

13-848

BOLT,Hex, 1/2" - 13 x 3", Gr 5

- 1/2" x 3" N.C., hex.

2шт.

4

A11190

TACHOMETER

ASSY. - engine

1шт.

5

A11191

CABLE ASSY. - tachometer

1шт.

6

A24523

KIT

CABLE - tachometer

1шт.

7

A10475

GAUGE - oil (Murphy)

1шт.

8

A11189

TUBE - oil gauge

1шт.

9

222-40

ELBOW,90 Degree, 3/8"-24 Fem x 1/8"-27 NPTF

- tube, 1/8" tube x 1/8" P.T.

1шт.

10

O10381AB

SNUBBER - oil gauge tube

1шт.

11

A24510

SWITCH

- starting (Diesel) includes keys

1шт.

12

A24509

KEY

- ignition start, Set of 2

2шт.

13

O3601AB1

X

AMMETER - electrical

1шт.

14

A23261

SWITCH

- relay

1шт.

15

A10471

GAUGE - engine temperature

1шт.

20

A11183

PANEL - instrument, Type 1 spark ignition units

1шт.

21

O8066AB

SPACER - instrument panel

4шт.

13-840

BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5

- 1/2" x 2-1/2" N.C., hex.

2шт.

13-848

BOLT,Hex, 1/2" - 13 x 3", Gr 5

- 1/2" x 3" N.C., hex.

2шт.

22

A11186

SHROUD - instrument panel

1шт.

187-986

SCREW - self-tap, #10 x 1/2" hex., hd.

6шт.

23

A11190

TACHOMETER

- engine

1шт.

24

A33740

CABLE ASSY. - tachometer

1шт.

25

A24523

KIT

CABLE - tachometer

1шт.

26

A10475

GAUGE ASSY. - oil (Murphy)

1шт.

27

A24511

SWITCH

- ignition, w/key (Gas)

1шт.

28

A24509

KEY

- ignition switch

2шт.

29

A11736

SPACER - ignition switch

1шт.

30

O3601AB1

X

GAUGE ASSY. - ammeter

1шт.

31

A10471

GAUGE ASSY. - temperature (Murphy)

1шт.

32

A23261

SWITCH

ASSY. - relay

1шт.

33

223-14

FUSE,10 Amp, Type SFE

- relay switch

1шт.

34

A11737

WASHER - retaining, starter switch

1шт.
