Запчасти Case IH 188 (36) - AIR CLEANER, MANIFOLD AND MUFFLER, DIESEL ENGINE
№
Артикул
Название
Примечание
Количество
1
A21430
CAP
- air cleaner
1шт.
2
A16898
BAND
- mounting, air cleaner
1шт.
3
173-216
SCREW,Sl Rnd Hd, 1/4" - 20 x 1 3/4"
- 1/4" x 1-3/4" rd.hd.(plated)
1шт.
4
129-104
NUT,7/16"-14, G5
- 1/4" N.C. sq.
1шт.
5
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
1шт.
6
G45473
AIR CLEANER - complete
1шт.
7
G46326
X
CUP - oil, inner
1шт.
8
G45333
CLAMP
ASSY - oil cup
1шт.
9
G46327
X
CUP - oil, outer
1шт.
10
G46338
INTAKE AIR HOSE,2.25" ID x 3.00", SAE 20R2
- Air cleaner to tube 2.25" ID x 3.00", SAE 20R2
1шт.
11
214-260
HOSE CLAMP,#36, 1.81" - 2.75", Type F Worm
2шт.
12
G45474
TUBE -, Serial Range: cleaner-manifold
1шт.
13
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
2шт.
14
92-6
LOCK WASHER,3/8"
2шт.
15
A15687
GASKET - tube to intake manifold
1шт.
16
A35782
MANIFOLD
- intake
1шт.
17
VT4510
X
STUD - manifold to head(3/8" x 1-3/4")
4шт.
18
92-6
LOCK WASHER,3/8"
4шт.
19
131-903
NUT,3/8"-16
NUT - 3/8" N.C.(Seez-Pruf)
4шт.
20
G46871
GASKET
- intake, Serial Range: manifold-head
1шт.
21
G46872
MANIFOLD GASKET
- exhaust, Serial Range: manifold-head
1шт.
22
G2113
EXHAUST MANIFOLD
MANIFOLD - exhaust
1шт.
23
A35175
STUD
- manifold clamp(3/8" x 2-7/16")
6шт.
24
25-106
NUT,3/8"-16, G5
- 3/8" N.C.hex
6шт.
25
92-6
LOCK WASHER,3/8"
6шт.
26
A35028
CLAMP
-, Serial Range: manifold-head
6шт.
27
G2044
LARGE PLATE
COVER - exhaust opening
1шт.
28
13-624
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
- 3/8" x 1-1/2" N.C. hex. hd.
2шт.
29
VT3362
X
NUT - brass, 3/8" N.C.
2шт.
30
G46853
MANIFOLD GASKET
- exhaust opening
2шт.
31
G2095
FITTING
ELBOW - exhaust outlet
1шт.
32
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
2шт.
33
92-6
LOCK WASHER,3/8"
2шт.
34
A13240
CLAMP,2-5/8" ID
- muffler
1шт.
35
25-115
NUT,5/16"-24, G5
- 5/16" NF hex
2шт.
36
92-5
LOCK WASHER,5/16"
2шт.
37
G45239
MUFFLER
1шт.
38
G45048
CAP
- weather
1шт.
Выбрано товаров: 38
