Запчасти Case IH 188 (34) - OIL FILTER, OIL PUMP AND OIL PAN, DIESEL ENGINE

Схема запчастей Case IH 188 - (34) - OIL FILTER, OIL PUMP AND OIL PAN, DIESEL ENGINE
6
4
2
18
16
13
15
11
9
10
12
3
8
14
1
17
19
5
7

Артикул

Название

Примечание

Количество

1

G45210

FILTER, ELEMENT

FILTER - oil

1шт.

2

G49074

ADAPTER -, Serial Range: filter-bracket

1шт.

3

G2122

BRACKET - filter mounting

1шт.

4

13-514

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5

2шт.

4

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

1шт.

6

13-536

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

1шт.

7

193-29

LOCK WASHER,Int Tooth, 5/16"

WASHER, LOCK, Int Tooth, 5/16"

4шт.

8

G46854

GASKET

-, Serial Range: bracket-block

1шт.

9

A49050

X

PUMP ASSY - complete

1шт.

10

VT3221

X

RETAINER - relief spring

1шт.

11

G48500

SPRING

- relief valve

1шт.

12

VT3298

X

VALVE - relief

1шт.

13

138-62

LOCK PIN,1/8" x 1 1/8", Slotted

PIN, 1/8" x 1 1/8", Slotted

1шт.

14

VT3356

PLUG - body

2шт.

15

G46852

GASKET

- pump cover

1шт.

16

O8416AB

X

"O" RING - port hole

1шт.

17

G11337

SHIM,.002" Thk

Pump to block .002" Thk

2шт.

18

G11338

SHIM,.005" Thk

Pump to block .005" Thk

1шт.

19

223-207

LOCK NUT

NUT - lock, Serial Range: pipe-pump

1шт.

20

G45766

PIPE, EXHAUST SYSTEM

PIPE - suction

1шт.

21

132-50

COTTER PIN,1/8" x 1 1/4"

Pin, Split (Cotter), 1/8" x 1 1/4"

1шт.

22

VTA330

FLOAT ASSY (includes screen)

1шт.

23

A36775

X

DIPSTICK - oil level (See items 25, 26 & 27)

1шт.

24

A36774

X

TUBE - oil filler & dipstick supp. (See items 25, 26 & 27)

1шт.

25

G37037

DIPSTICK

- oil level (See items 23 & 24)

1шт.

26

G46892

OIL SEAL

- rubber (used w/G37037 dipstick)

1шт.

27

G45139

BRACKET

SUPPORT - dipstick (See items 23 & 24)

1шт.

28

A40712

KIT

GASKET KIT - oil pan (incl. item 31)

1шт.

29

A36782

PAN

OIL PAN ASSY

1шт.

30

A14280

PLUG

- drain (3/4"-16) (See item 32)

1шт.

31

A27927

OIL PAN GASKET SET

- drain plug ( replaced O9844AB )

1шт.

REF#31 REPLACED BY A27927,NOTE:THERE IS ALSO A NYLON GASKET AVAILABLE PART #A58608.

1шт.

32

G45786

PLUG

ASSY - drain (3/8" P.T.) (See item 30)

1шт.

33

G46903

GASKET

- plug

1шт.

34

193-514

SCREW,SEMS, Hex Hd, 5/16"-18 x 3/4"

BOLT - (includes lockwasher)

16шт.
