Запчасти Case IH FVAE2884X B200 (3260.001) - TEMPERATURE REGULATOR oil heat exchanger

1

504062828

OIL COOLER

OIL/WATER HEAT EXCHANGER, ASSY

1шт.

2

4863369

O-RING

O-RING, dia=46,99x5,33 MM

2шт.

3

16587425

BOLT,M10 x 1.5 x 40mm

HEXAGON BOLT, M10X40 MM

6шт.

4

8094798

COVER

HEAT EXCHANG.COVER

1шт.

5

8094799

COVER

HEAT EXCHANG.COVER

1шт.

6

8094800

OIL COOLER

TUBE STACK

1шт.

7

8029428

SPACER

SPACING BAR

1шт.

8

16690924

SCREW,M8 x 40mm

CYLIND-HEAD SCREW, M8X40 MM

8шт.

9

8030481

HYD TUBE

O-RING, dia=142,47X3,53 MM

4шт.
