Запчасти Case IH F5AE9454D A001 (3490.009) - FAN SUPPORT

1

504255372

SUPPORT

SUPPORT

1шт.

2

4892732

BALL BEARING,34mm ID x 64mm OD x 37mm W

BALL BEARING

1шт.

3

4890732

RETAINER,11.50mm ID x 52mm OD x 7mm

WASHER

1шт.

4

32324

SNAP RING,2.44", Int, #244

SPRING LOCKWASHER

1шт.

5

2852172

BOLT,Flng, M10 x 1.5 x 70mm

HEXAGON BOLT, M10X70 MM

1шт.

6

16673835

BOLT,Hex, M8 x 30mm

HEXAGON BOLT, M8X30 MM

5шт.

7

504255369

PULLEY

PULLEY

1шт.

8

18139424

SCREW,Hex, M10 x 20mm

HEXAGON BOLT, M10X20 MM

4шт.
