Запчасти Case IH F4HFE413H B004 (10.400.AE) - COOLANT HEATING LINES (10) - ENGINE

1

2852923

SCREW

M10 x 1.5 x 90

3шт.

2

2854072

SEALING RING,Square, 5.16mm Thk x 50.17mm ID

2шт.

3

47536450

SUPPORT

ASSY, Incl 4 - 5

1шт.

4

NSS

NOT SOLD SEPARAT

Support; Incl in 1

1шт.

5

98405182

DOWEL

2шт.

6

2852922

ELBOW

1шт.

7

4895392

HEX SOCKET PLUG,M18 x 1.5

ASSY, Incl 8 - 9

2шт.

8

4895394

HEX SOCKET PLUG,M18 x 1.5

1шт.

9

4895393

O-RING,2.2mm Thk x 15.3mm ID

1шт.

10

4895623

HEX SOCKET PLUG,M16 x 1.5

ASSY, Incl 11 - 12, Inlet

1шт.

11

NSS

NOT SOLD SEPARAT

Plug, Incl in 11

1шт.

12

4895625

O-RING,13.3mm ID x 2.2mm Width

1шт.

13

NSS

NOT SOLD SEPARAT

Plug, Incl in 14

1шт.

14

4895080

HEX SOCKET PLUG,M22 x 1.5

ASSY, Incl 13, 15

2шт.

15

4895082

O-RING,19.3mm ID x 2.2mm Width

ID = 19.3 x 2.2

2шт.

16

4893036

PIPE PLUG,3/4"-14 NPTF

1шт.

16

2854866

HEX SOCKET PLUG,3/4"-14 NPTF

Alternative

1шт.

17

4895078

PIPE PLUG,1/2"-14

3шт.

18

47565455

FITTING,M12 x 1.5 x 20mm D

1шт.

19

4893036

PIPE PLUG,3/4"-14 NPTF

PLUG-THREADED

1шт.
