Запчасти Case IH F4GE9684B J605 (10.103.01) - SHORT BLOCK - CRANKSHAFT (504384710 - 504057569) (10) - ENGINE

1

2852305

CRANKSHAFT

- ASSY Contains Ref.1A, 2, 3

1шт.

1a

NSS

NOT SOLD SEPARAT

1шт.

2

4893386

GEAR,36 T

1шт.

3

4899046

DOWEL,M6 x 9 L

1шт.

4

2992147

SET OF STD MAIN BRGS

STD.

6шт.

4

2992148

SET OF MAIN BRGS-.25

(-0.254) (-0.250)

6шт.

4

2992149

SET OF MAIN BRGS -

(-0.508) (-0.500)

6шт.

5

2992153

CAP

(+0.000) (+0.000)

1шт.

5

2992154

SET OF THRUST WASHER

(+0.254) (+0.250)

1шт.

5

2992155

SET OF THRUST WASHER

(+0.508) (+0.500)

1шт.

6

4892438

GEAR,36T

1шт.
