Запчасти Case IH F4CE9484L J603 (10.105.01) - PISTON - ENGINE (2859354) (10) - ENGINE

Схема запчастей Case IH F4CE9484L J603 - (10.105.01) - PISTON - ENGINE (2859354) (10) - ENGINE
2
4
1
5
home
4
10.105.02
3
6

Артикул

Название

Примечание

Количество

1

2854603

PISTON RING

STD

4шт.

1

2856713

PISTON RING

Oversize 0.4 mm

4шт.

1

2856714

PISTON RING

Oversize 0.8 mm

4шт.

2

2830158

PISTON RING,95.4mm ID x 104mm OD x 2.39mm Thk

STD

4шт.

2

2830159

PISTON RING,95.4mm ID x 104.4mm OD x 2.39mm Thk

Oversize 0.4 mm

4шт.

2

2830160

PISTON RING

Oversize 0.8 mm

4шт.

3

2852037

SEAL,95.3mm ID x 104mm OD x 4mm Thk

STD

4шт.

3

2853875

OIL SCRAPER RING +0.,95.3mm ID x 104mm OD

Oversize 0.4 mm

4шт.

3

2853876

PISTON RING

Oversize 0.8 mm

4шт.

4

2854030

SNAP RING,M40.8 OD

8шт.

5

4892712

PISTON PIN,38mm OD x 82mm L

4шт.

6

2859355

PISTON

STD

4шт.

6

84180248

PISTON ASSY +0.4

Oversize 0.4 mm

4шт.

6

84362277

PISTON

Oversize 0.8 mm

4шт.

Выбрано товаров: 14
