Запчасти Case IH F3DFA613B E003 (10.103.01) - CRANKSHAFT & RELATED PARTS (504386695) (10) - ENGINE

1

504388345

CRANKSHAFT

ASSY Contains Ref,1A, 2, 3

1шт.

1a

NSS

NOT SOLD SEPARAT

1шт.

2

99437423

DRIVING GEAR

1шт.

3

10839610

DOWEL,M8 x 12mm

1шт.

4

8097824

SET OF STD MAIN BRGS

RED

1шт.

4

8097825

SET OF STD MAIN BRGS

GREEN

1шт.

4

8097826

SET OF STD MAIN BRGS

RED BLACK

1шт.

4

8097827

SET OF STD MAIN BRGS

GREEN BLACK

1шт.

5

8097828

SET OF THRUST WASHER

STANDARD RED

1шт.

5

8097831

SET OF THRUST WASHER

STANDARD GREEN

1шт.

5

8097832

SET OF THRUST WASHER

RED BLACK

1шт.

5

8097833

SET OF THRUST WASHER

GREEN BLACK

1шт.
