Запчасти Case IH F3CE0684F E001 (10.402.01[03]) - PIPING - ENGINE COOLING SYSTEM (504057436-504057441-504031565-504031567-504069778-504236475) (01) - ENGINE

1

16992515

PLUG

M18 x 1.5

2шт.

2

4893207

SEALING WASHER,15.5mm ID x 26mm OD x 1.5mm Thk

D = 18 x 26 mm SP=1,5 mm

2шт.

3

10300714

PLUG,M16 x 1.5 x 14

M16 x 1.5

2шт.

4

99489019

SEALING WASHER

D = 16 x 24 mm SP=1,5 mm

2шт.

5

10305171

PLUG,M22 x 1.5 x 21

M22 x 1.5

1шт.

6

87332142

SEAL,23.5mm ID x 30mm OD x 1.5mm Thk

D = 22 x 30 mm SP=1,5 mm

1шт.

7

4665029

PLUG

M42 x 1.5

1шт.

8

99469382

SEAL

D = 42 x 50 x 2 mm

1шт.
