Запчасти Case IH F3BE0684A B001 (0.35.0[01]) - BELT PULLEY DRIVE & COVER (500387625)

1

500353779

SUPPORT

- ASSY

1шт.

2

98472270

PLUG

1шт.

3

4788087

BUSHING,36.57mm ID x 40.98mm OD x 17.2mm L

2шт.

4

504026315

PTO SHAFT

1шт.

5

500351319

LOCK WASHER

1шт.

6

500382573

GEAR

1шт.

7

500382574

LOCK WASHER

1шт.

8

17046231

NUT

1шт.

9

14466981

O-RING,0.139" Thk x 5.109" ID, -251, Cl 7, 75 Duro

D=126.59 x 3.53 mm

1шт.

10

14456881

O-RING,0.362" ID x 0.103" Width

D=9.19 mm

1шт.

11

16678134

SCREW,M12 x 45mm

M12X45 mm

3шт.

12

500355018

GASKET

1шт.

13

500355019

COVER

1шт.

14

16587024

FLANGE BOLT,Hex, M10 x 20mm, Cl 8.8, Full Thd

M10X20 mm

4шт.
