Запчасти Case IH F3AE0684P E909 (0.32.4) - PIPING - ENGINE COOLING SYSTEM (504057436-504057441-504031565-504031567-504069778-504236475)

1

16992515

PLUG

M18 x 1.5

2шт.

2

4893207

SEALING WASHER,15.5mm ID x 26mm OD x 1.5mm Thk

D. 18x26 mm SP=1,5 mm

2шт.

3

10300714

PLUG,M16 x 1.5 x 14

M16 x 1.5

2шт.

4

99489019

SEALING WASHER

D. 16x24 mm SP=1,5 mm

2шт.

5

10305171

PLUG,M22 x 1.5 x 21

M22 x 1.5

1шт.

6

87332142

SEAL,23.5mm ID x 30mm OD x 1.5mm Thk

D. 22x30 mm SP=1,5 mm

1шт.

7

4665029

PLUG

M42 x 1.5

1шт.

8

99469382

SEAL

1шт.
