Запчасти Case IH F2CFE614D A004 (50.200.01 02) - COMPRESSOR, AIRCOND. (504387497) (50) - CAB CLIMATE CONTROL

1

504308489

AIR COMPRESSOR

1шт.

2

87520321

GEAR

1шт.

3

504016500

NUT

1шт.

4

10520304

WASHER,18.8mm ID x 32mm OD x 4mm Thk

1шт.

5

16587024

FLANGE BOLT,Hex, M10 x 20mm, Cl 8.8, Full Thd

2шт.

6

14456881

O-RING,0.362" ID x 0.103" Width

1шт.

7

14466981

O-RING,0.139" Thk x 5.109" ID, -251, Cl 7, 75 Duro

1шт.

8

16693924

BOLT

3шт.

9

504016778

GASKET,0.8mm Thk

1шт.

10

504016777

COVER

1шт.
