Запчасти Case IH F2CFA613A E001 (10.210.AO) - FUEL SYSTEM, PUMP AND FILTER (10) - ENGINE

1

84574486

1шт.

2

86010402

CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type

1шт.

3

86999949

FUEL FILTER

1шт.

4

84132594

SPACER,10.7mm ID x 17.1mm OD x 30mm OAL

1шт.

5

150018

HYD CONNECTOR,M18 x 1.5 x 28

1шт.

6

84574487

1шт.

7

84301648

HOSE,10mm ID x 2560mm L, SAE 100R6

1шт.

8

87283963

INSULATOR

1шт.

9

87035448

SPACER,8.48mm ID x 12.7mm OD x 12.7mm L

2шт.

10

578070

CLAMP,19mm, Coat, 8.7mm Bolt Hole, P Type

2шт.

11

86999948

SAFETY VALVE

1шт.

12

84302861

HOSE

2шт.

13

86999947

GROMMET,25mm ID x 33mm OD, 46mm Shoulder

1шт.

14

87105416

HOSE PROTECTION,16.64 mm ID x 1345.00 mm

1шт.

15

84574485

1шт.

16

87743277

CONDUIT

1шт.

17

84331258

FILTER STRAINER

1шт.

18

84069089

HYD CONNECTOR,M18 x 1.5 NPT

1шт.

19

84011517

DRAINCOCK/TAP SUPPLY,1/4" x 1/4"

1шт.

20

84547307

FUEL TUBE

1шт.

21

201-326

ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 7/8" - 14 Male ORB

1шт.

22

86512512

PLUG,7/8" - 14 ORB

2шт.

23

87676818

FUEL PUMP,12V, 4.5A

1шт.

24

201-327

ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 1-1/16" - 12 Male ORB

1шт.

25

120056

BOLT,M6 x 1.0 x 54.15mm, Cl 8.8

1шт.

26

43128

BOLT,M8 x 1.25 x 30mm, Cl 8.8

1шт.

27

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

2шт.

28

120069

BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8

1шт.

29

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

10шт.

30

9706704

BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8

2шт.

31

201-327

ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 1-1/16" - 12 Male ORB

1шт.

31

412649

BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk

2шт.

32

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

7шт.

33

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

3шт.

34

353308

NUT,M6 x 1.0, Cl 8

1шт.

35

9706690

NUT,M8 x 1.25, Cl 8

4шт.

36

100016

NUT,M10 x 1.5, Cl 8

1шт.

37

84354931

FITTING

1шт.

38

9706748

CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type

2шт.

39

87532245

1шт.

40

433008

CLAMP

2шт.

41

84313864

FUEL FILTER

1шт.

42

86637701

HOSE CLAMP,12.45mm - 12.95mm

2шт.

43

2830987

SENSOR

1шт.

44

84469344

HYD CONNECTOR

2шт.
