Запчасти Case IH DTI-466B (9E-096) - HYDRAULIC HEAD

684320C93

ROTOR

HEAD ASSEMBLY - hydraulic, used with pump assembly 1809633C91, Includes: Ref. 2 - 23

1шт.

674839C94

HEAD

ASSEMBLY - hydraulic, used with pump assembly 1806912C91, Includes: Ref. 2 - 23

1шт.

2

674800C1

SCREW

- set, no longer available

1шт.

3

211-1006

BALL,3/16" Dia

- sealing, chrome alloy steel, 3/16 inch, grade 24 (Replaces ball 674784C1)

1шт.

4

684399C1

FITTING

- discharge, not shown

6шт.

5

674786C2

NUT,3/4" - 20

- delivery valve cap

1шт.

684934C93

PACKAGE, REPAIR

KIT - delivery valve service, Includes: Ref. 6 - 10

1шт.

6

674785C1

GASKET

- cap nut

1шт.

7

NSS

NOT SOLD SEPARAT

HOLDER - delivery valve, order kit 684934C93

1шт.

8

674801C1

SPRING

- delivery valve

1шт.

9

674789C1

GUIDE

- delivery valve spring, 0.056 inch, yellow

1шт.

9

674790C1

GUIDE

- delivery valve spring, 0.066 inch, red

1шт.

9

674791C1

GUIDE

- delivery valve spring, 0.076 inch, blue

1шт.

9

674792C1

GUIDE

- delivery valve spring, 0.086 inch, black

1шт.

9

674793C1

GUIDE

- delivery valve spring, 0.096 inch, white

1шт.

10

NSS

NOT SOLD SEPARAT

VALVE - delivery, order kit 684934C93

1шт.

12

238-5144

O-RING,0.103" Thk x 2.487" ID, -144, Cl 5, 75 Duro

- upper, 2-1/2 ID x 3/32 inch wide (Replaces O-ring 327110R1)

1шт.

13

674772C1

GASKET

O-RING - lower

1шт.

14

681426C1

GUIDE

- plunger drive

1шт.

15

681496C1

RETAINER

- face gear

1шт.

16

674798C2

THRUST WASHER

- thrust

1шт.

17

681439C91

GEAR

AND HUB ASSEMBLY - face, Includes: Ref. 17A & 17B

1шт.

17a

1802397C1

GEAR

- face, not illustrated

1шт.

17b

1802399C1

HUB

- face gear, not illustrated

1шт.

18

674804C1

WASHER

- plunger spring

1шт.

19

674802C1

SPRING

- plunger

1шт.

20

684301C1

SEAT - lower spring, no longer available

1шт.

21

674797C1

RING

- lower spring seat split

2шт.

22

674949C2

VALVE

BUTTON - plunger, identification A, 0.0171 inch

1шт.

22

674925C2

VALVE

BUTTON - plunger, identification B, 0.1091 inch

1шт.

22

674926C2

VALVE

BUTTON - plunger, identification C, 0.1110 inch

1шт.

22

674948C2

VALVE

BUTTON - plunger, identification D, 0.1130 inch

1шт.

22

674775C2

VALVE

BUTTON - plunger, identification E, 0.1150 inch

1шт.

22

674776C2

VALVE

BUTTON - plunger, identification F, 0.1169 inch

1шт.

22

674777C2

VALVE

BUTTON - plunger, identification G, 0.1189 inch

1шт.

22

674778C2

VALVE

BUTTON - plunger, identification H, 0.1209 inch

1шт.

22

674779C2

VALVE

BUTTON - plunger, identification J, 0.1228 inch

1шт.

22

674780C2

VALVE

BUTTON - plunger, identification K, 0.1248 inch

1шт.

22

674781C2

VALVE

BUTTON - plunger, identification L, 0.1268 inch

1шт.

22

674782C2

VALVE

BUTTON - plunger, identification M, 0.1287 inch

1шт.

23

674783C1

RING

- plunger button retaining

1шт.
