Запчасти Case IH DTI-466B (9E-040) - CLIPS, SERVICE KITS

384554R1

CLIP

- retaining, cable, assemble to front breather body bolt

1шт.

673193C1

CLIP

- tube, mounted at breather housing rear most bolt

1шт.

399657R1

CLIP

- engine harness, cable, assemble to top left-hand side front plate

1шт.

674399C96

GASKET

KIT - crankcase gasket, Includes: Parts Listed Below

1шт.

1

682945C3

GASKET

- flywheel housing

1шт.

59658D

WASHER,22.62mm ID x 32.54mm OD x 1.72mm Thk

GASKET - oil pan drain plug

1шт.

2

677711C2

GASKET

BAFFLE - breather

1шт.

673185C1

O-RING

- breather pipe

1шт.

3

675609C2

GASKET

- injection pump adapter

1шт.

4

675398C2

GASKET

- oil filter base

1шт.

675513C1

OIL SEAL

SEAL - oil cooler mounting

2шт.

261624R1

GASKET

- regulator valve cap

1шт.

682444C1

RING

- camshaft seal

1шт.

680084C97

GASKET KIT

KIT - crankcase, front cover gasket

1шт.

1342422C2

GASKET KIT

KIT - cylinder head gasket (Replaces kits 674398C96 and 1808973C91), Includes: Parts Listed Below

1шт.

5

1349062C1

MANIFOLD GASKET

- exhaust manifold (Replaces gasket 688928C1)

6шт.

6

1342839C1

MANIFOLD GASKET

- intake manifold (Replaces gasket 682199C1)

1шт.

7

1342826C1

GASKET

- turbocharger (Replaces gasket 670073C1)

1шт.

8

1342834C1

GASKET

- turbocharger oil inlet tube (Replaces gasket 253660R1)

1шт.

1342827C1

SHIELD

GASKET - oil rotator

1шт.

1342835C1

GASKET

- oil drain tube (Replaces gasket 687903C1)

1шт.

1342836C1

GASKET

- thermostat housing (Replaces gasket 675384C1)

1шт.

9

1342421C2

CYLINDER HEAD GASKET

- cylinder head (Replaces gasket 1806226C1)

1шт.

10

1342828C1

GASKET

- valve cover (Replaces gasket 675109C2)

1шт.

11

1342829C1

GASKET

- nozzle, injector (Replaces gasket 675477C1)

6шт.

1342832C1

GASKET

- breather housing, valve cover (Replaces gasket 673973C4)

1шт.

1342838C1

GASKET

- intercooler air inlet elbow (Replaces gasket 686181C1)

1шт.

1342831C1

SEAL

GROMMET - injection dust cover (Replaces grommet 682810C1)

6шт.

1342830C1

SEAL

GROMMET - valve cover (Replaces grommet 677692C1)

6шт.

1342837C1

MANIFOLD GASKET

- intake manifold elbow (Replaces gasket 673341C1)

1шт.

1342827C1

SHIELD

- oil rotator (Replaces shield 681234C1)

12шт.

680084C97

GASKET KIT

KIT - crankcase front cover gasket, Includes: Parts Listed Below

1шт.

12

675813C2

GASKET,0.79mm Thk

- crankcase front cover

1шт.

677082C3

GASKET

- front cover

1шт.

13

675812C2

GASKET

- crankcase front plate

1шт.

683791C1

GASKET

- crankcase front plate

1шт.

14

675816C2

GASKET,0.79mm Thk

- injection pump access cover

1шт.

671821C2

GASKET

- lubrication oil pump inlet

1шт.

1802867C1

GASKET

- oil pump inlet tube, for tube 1806843C1

1шт.

671825C4

GASKET

- oil pan, used with 300 series engines

1шт.

671827C4

OIL PAN GASKET SET

- oil pan, used with 400 series engines, not used with oil pan 1806454C91

1шт.

673396C2

GASKET

- water inlet elbow

1шт.

15

675808C2

GASKET,0.79mm Thk

- water pump housing

1шт.

238-5218

O-RING,0.139" Thk x 1.234" ID, -218, Cl 5, 75 Duro

Oil cooler tube -218, 70 Duro, 1.234" ID x .139" Thk

4шт.

675860C1

RING

O-RING - oil pump housing

2шт.

676988C1

GASKET

- water pump bearing housing

1шт.

674754C1

GASKET

GASKET - injection pump mounting

1шт.
