Запчасти Case IH DT-429 (9-16) - CLIPS, SERVICE KITS

362126R1

CLIP

CLAMP - thermostat housing

1шт.

362126R1

CLIP

CLAMP - front cover

1шт.

363660R1

CLIP

CLAMP - front cover

2шт.

362120R1

CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type

CLAMP - P-type, front cover

1шт.

366460R1

CABLE CLIP

CLIP - harness, front cover

1шт.

362667R1

CLIP

CLAMP - retainer, valve cover

1шт.

362126R1

CLIP

CLAMP - valve cover

1шт.

114-221

BOLT,Hex, 3/8" - 24 x 5/8", Gr 5, Full Thd

- hex, 3/8 NF x 5/8 inch (Replaces bolt 181356)

1шт.

92-11038

LOCK WASHER,3/8"

WASHER, LOCK, (Replaces washer 103321) 3/8"

1шт.

345289R93

STRIPPER PACKAGE

KIT - crankcase gasket, no longer available, Includes: Parts Listed Below

1шт.

326641R1

GASKET

- auxiliary drive housing, no longer available

1шт.

1

326647R1

GASKET

- breather elbow, no longer available

1шт.

304573R1

GASKET

- cranking motor

1шт.

2

332300R1

GASKET

- flywheel housing

1шт.

3

607464C1

GASKET

- front cover

1шт.

4

326622R2

GASKET

- front plate, no longer available

1шт.

5

326831R1

GASKET - hydraulic pump hole cover

1шт.

6

326582R2

GASKET

- injection pump cover

1шт.

7

326962R1

SEAL ASSY.

GASKET - oil filler elbow

1шт.

8

345193R1

GASKET - oil gallery inlet elbow, no longer available

1шт.

326809R1

GASKET - oil level gauge tube flange, no longer available

1шт.

332414R1

GASKET

- oil outlet elbow

1шт.

328936R1

GASKET

- oil pan lower

1шт.

9

341391R1

GASKET

- oil pan upper

1шт.

10

349065R1

GASKET

- oil pump cover

1шт.

607130C2

GASKET

- oil pump inlet tube

1шт.

318424R1

GASKET - oil seal face plate, no longer available

1шт.

326653R1

GASKET - PTO housing, no longer available

1шт.

11

332214R1

GASKET

- push rod cover

2шт.

12

330457R1

GASKET

- thermostat housing

1шт.

328700R1

GASKET

- water inlet elbow, no longer available

1шт.

13

326988R1

GASKET

- water outlet housing

1шт.

14

349254R1

GASKET

- water pump, no longer available

1шт.

51527DC

GASKET

- water trap

1шт.

238-5214

O-RING,0.139" Thk x 0.984" ID, -214, Cl 5, 75 Duro

Breather pipe -214, 70 Duro, .984" ID x .139" Thk

1шт.

238-5214

O-RING,0.139" Thk x 0.984" ID, -214, Cl 5, 75 Duro

Cooler to flywheel housing -214, 70 Duro, .984" ID x .139" Thk

1шт.

238-5250

O-RING,0.139" Thk x 4.984" ID, -250, Cl 5, 75 Duro

-250, 70 Duro, 4.984" ID x .139 Thk, Equipment pump drive cover (Replaces O-ring 22414R1)

1шт.

308459R1

RING

O-RING - filter bolt

2шт.

238-5224

O-RING,0.139" Thk x 1.734" ID, -224, Cl 5, 75 Duro

Idler shaft hole plug -224, 70 Duro, 1.734" ID x .139" Thk

1шт.

346895R1

WIPER SEAL

SEAL - injection pump

1шт.

238-5227

O-RING,0.139" Thk x 2.109" ID, -227, Cl 5, 75 Duro

Oil cooler outlet tube -227, 70 Duro, 2.109" ID x .139" Thk

2шт.

238-5113

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

Oil gallery plug (Replaces seal 352221R1) -113, 70 Duro, .549" ID x .103" Thk

2шт.

343396R2

SEALING RING

O-RING - oil pump tube

4шт.

601141C1

GASKET

O-RING - piston cooling tube

12шт.

238-5230

O-RING,0.139" Thk x 2.484" ID, -230, Cl 5, 75 Duro

PTO drive -230, 70 Duro, 2.484" ID x .139" Thk

2шт.

349055R2

RING

O-RING - safety valve assembly

1шт.
