Запчасти Case IH DT-361 (8-22) - SHORT BLOCK ENGINE, SERVICE KITS

749554C91

ENGINE - block, short, remanufactured, D-361 engine (North America only), no longer available

1шт.

1928049C1

CORE-ENGINE

RETURN NUMBER - use this part number to return engine for credit when using a remanufactured assembly

1шт.

601189C91

ENGINE - block, short, new, D-361 engine, used with 806 and 2806 tractors, consists of: camshaft, connecting rod and bearings, crankcase, crankshaft and bearings, piston with pins and rings, valve tappets

1шт.

349293R91

ENGINE - block, short, DT-361 engine, used with 1206 and 21206 tractors, consists of: camshaft, connecting rod and bearings, crankcase, crankshaft and bearings, piston with pins and rings, valve tappets, and injection pump idler gear, no longer available

1шт.

345287R94

GASKET

KIT - crankcase gasket, Includes: Parts Listed Below

1шт.

345247R1

GASKET

- cooler header rear

1шт.

328939R1

GASKET

- cooler header rear

1шт.

1

332544R1

GASKET

- crankcase oil outlet elbow

1шт.

2

328846R1

GASKET

- crankcase rear plate

1шт.

304573R1

GASKET

- cranking motor

1шт.

3405H

GASKET

- drain plug

1шт.

3

326580R1

GASKET

- front cover

1шт.

4

328735R1

GASKET

- front plate

1шт.

318335R1

GASKET

- fuel line screw

12шт.

5

332566R1

GASKET

- header tube flange

1шт.

6

278347R1

GASKET

- fuel injection pump, International R.D.

1шт.

346895R1

WIPER SEAL

- fuel injection pump, Roosa-Master

1шт.

7

326582R2

GASKET

- injection pump cover

1шт.

328842R1

GASKET

- injection pump mounting plate

1шт.

8

601381C1

GASKET

- oil pump cover

1шт.

9

326813R1

GASKET

- oil cooler

2шт.

9

337242R1

GASKET

- oil cooler header

2шт.

326597R1

GASKET

- oil cooler elbow

2шт.

332555R1

GASKET

- oil cooler flange, inlet and outlet

2шт.

328672R1

GASKET - oil filler elbow

1шт.

10

328731R2

OIL PAN GASKET SET

- oil pan

1шт.

332549R1

GASKET

- oil pump inlet

1шт.

332536R1

GASKET

- oil pump mounting

1шт.

11

332303R1

SEAL

- seal, face plate

1шт.

12

328739R1

GASKET

- valve push rod cover

2шт.

328892R1

GASKET

- water pump

1шт.

350818R1

O-RING,0.984" ID x 0.139" Width

- breather tube

1шт.

343398R2

RING

O-RING - cooler to filter tube

2шт.

343396R2

SEALING RING

O-RING - cooler to filter tube

2шт.

343396R2

SEALING RING

O-RING - crankcase to pump tube

2шт.

238-5250

O-RING,0.139" Thk x 4.984" ID, -250, Cl 5, 75 Duro

-250, 70 Duro, 4.984" ID x .139 Thk, Equipment pump drive cover (Replaces O-ring 252735R1)

1шт.

308459R1

RING

O-RING - filter bolt

2шт.

343398R2

RING

O-RING - filter header to cooler header tube

1шт.

238-5266

O-RING,0.139" Thk x 7.984" ID, -266, Cl 5, 75 Duro

- flywheel housing cover (Replaces O-ring 384149R1)

1шт.

303545R1

O-RING

- fuel line elbow

1шт.

238-5223

O-RING,0.139" Thk x 1.609" ID, -223, Cl 5, 75 Duro

- idler gear shaft, 1-3/4 ID x 1/8 inch wide (Replaces O-ring 360610R1)

1шт.

349055R2

RING

O-RING - oil pump safety valve

1шт.

343398R2

RING

O-RING - pump to cooler tube

2шт.

238-5150

O-RING,0.103" Thk x 2.862" ID, -150, Cl 5, 75 Duro

PTO drive (Replaces O-ring 343831R1) -150, 70 Duro, 2.862" ID x .103" Thk

2шт.

238-5132

O-RING,0.103" Thk x 1.737" ID, -132, Cl 5, 75 Duro

- tachometer drive, 1-3/4 ID x 3/32 inch wide (Replaces O-ring 382781R1)

1шт.

238-5254

O-RING,0.139" Thk x 5.484" ID, -254, Cl 5, 75 Duro

Water pump (Replaces O-ring 285253R1) -254, 70 Duro, 5.484" ID x .139" Thk

1шт.

345441R1

WASHER

- bolt

2шт.

59657D

WASHER,13.1mm ID x 19.05mm OD x 1.58mm Thk

- filter bolt

2шт.

119937

GASKET,Copper, 1/2" x 11/16"

WASHER - filter drain

2шт.

345288R94

KIT

- gasket, valve grinding, Includes: Parts Listed Below

1шт.

13

327755R1

GASKET

- air intake

1шт.

609402C1

GASKET

- breather cover

1шт.

14

606073C2

CYLINDER HEAD GASKET

- cylinder head

1шт.

334035R1

GASKET - air intake upper elbow

1шт.

188275A1

MANIFOLD GASKET

- exhaust manifold (Replaces gasket 326523R1)

6шт.

601076C1

WASHER,9.42mm ID x 17.27mm OD x 1.68mm Thk

GASKET - nozzle

6шт.

326820R1

GASKET

- thermostat housing

1шт.

326818R1

GASKET

- thermostat housing elbow

2шт.

327761R1

GASKET

- turbo adapter

1шт.

341464R1

GASKET

- turbo oil drain

1шт.

15

328678R1

GASKET

- valve cover

1шт.

934662R1

SEALING RING,10mm ID x 14mm OD x 1mm Thk

GASKET - valve cover bolt

1шт.

238-5118

O-RING,0.103" Thk x 0.862" ID, -118, Cl 5, 75 Duro

Injection nozzle, dust (Replaces O-ring 364879R1) -118, 70 Duro, .862" ID x .103" Thk

6шт.
