(C-07) - FAN BLADES AND SPACERS, BELTS

Запчасти Case IH V-392 (C-07) - FAN BLADES AND SPACERS, BELTS

Схема запчастей Case IH V-392 - (C-07) - FAN BLADES AND SPACERS, BELTS
1
2
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

531944R1

FAN

BLADE ASSY, fan

1шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

8шт.

19797R1

BOLT (SPREADER),1/4" x 4 1/4", Gr 5

SCREW, 1/4-28 x 4-1/4 hex-hd cap

8шт.

2

296645C1

SPACER

fan, used w/sheet metal pulley only

2шт.

2

320287R1

SPACER, fan, used w/sheet metal pulley only

1шт.

3

(Not used in this application)

1шт.

402253R91

SET OF BELTS,0.50" W x 68.00" L

SET OF 2 BELTS , V-Belt, Matched 0.50" W x 68.00" L

1шт.
