Запчасти Case IH V-304 (A-27) - EXHAUST SYSTEM

1

217947R92

MANIFOLD ASSY, intake

1шт.

151629R1

BOLT,Hex, 3/8" - 16 x 1", Gr 8, Full Thd

3/8 NC x 1 hex-hd

8шт.

151225R1

SCREW,Hex, 3/8" - 16 x 1 1/4"

BOLT, 3/8 NC x 1-1/4 hex-hd

4шт.

354921R1

BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 8

3/8 NC x 1-1/2 hex-hd

4шт.

1597Q

WASHER, 3/8 flat

6шт.

681257R1

PLATE

PLUG, 7/8 expansion

2шт.

681258R1

PLATE

PLUG, 1-1/8 expansion

1шт.

2

103879

PLUG, 3/8 NPT pipe

1шт.

3

217-519

DRAIN PLUG,Sq Hd, 1/2"-14 NPTF

PLUG, , Pipe Sq Hd, 1/2"-14 NPTF

1шт.

4

103878

PLUG

1/4 sq-hd pipe

1шт.

5

151224R2

MANIFOLD GASKET

intake manifold

2шт.

6

531844R2

MANIFOLD GASKET

exhaust manifold

1шт.

7

531846R1

COVER, exhaust manifold end

2шт.

159689R1

WASHER

WASHER, tab lock

6шт.

531847R1

BOLT

exhaust manifold end cover

6шт.

8

531845R1

SHIM

GASKET, exhaust manifold end

2шт.

9

531745R1

MANIFOLD

exhaust

2шт.

151225R1

SCREW,Hex, 3/8" - 16 x 1 1/4"

BOLT, 3/8 NC x 1-1/4 hex-hd

2шт.

151364R1

SCREW,Hex, 3/8" - 16 x 2"

BOLT, 3/8-16 x 2 hex-hd cap

4шт.

105580H

BOLT

3/8 NC x 3-1/4 hex-hd

4шт.

159689R1

WASHER

WASHER, tab lock

8шт.

95-11041

WASHER,3/8"

13/32 x 13/16 x 16 ga exhaust manifold mtg

2шт.
