Запчасти Case IH DV4D (L-03) - COMPLETE SERVICE ENGINE

Схема запчастей Case IH DV4D - (L-03) - COMPLETE SERVICE ENGINE

Артикул

Название

Примечание

Количество

69561C91

COMPLETE SERVICE ENGINE, consists of all engine parts except muffler and exhaust pipe

1шт.

70035C91

PACKAGE, fuel pump repair

1шт.

Consists of (1) diaphragm (NSS), (1) gasket, cover (NSS), (2) valve & cage assy (NSS), (2) gasket, valve & cage (NSS), (1) bushing (NSS), (1) linkage (NSS), (1) gasket, mounting (NSS), (1) gasket, diaphragm (NSS), (1) spring (NSS), (1) pin (NSS)

1шт.

71009C91

PACKAGE, fuel strainer repair, consists of (1) bowl, glass (NSS) (1) gasket, bowl, (NSS), (1) filter (NSS) service packages

1шт.

71025C1

PACKAGE, valve grinding gasket, consists of the following gaskets (6) manifold (NSS), (6) manifold inset (NSS), (2) cylinder head (NSS), (4) valve inspection cover (NSS) service packages

1шт.

70506C91

SET

PACKAGE, gasket

1шт.

Consists of the following gaskets (6) manifold (NSS), (6) manifold insert (NSS), (3) carburetor (NSS), (1) fuel pump adapter (NSS), (1) fuel pump (NSS), (1) oil filter (NSS), (4) valve inspection cover (NSS), (1) flange (NSS), (3) main bearing, .003 (NSS), (3) main bearing, .006 (NSS), (1) governor housing (NSS), (2) cylinder base (NSS0, (1) gear cover (NSS), (1) crankcase (NSS), (1) bottom cover (NSS), (2) cylinder head (NSS)

1шт.

407487R1

SET

universal spark plug wire, service packages

1шт.

407487R1GV

SET

Value, Package, Ignition Cable

1шт.

71603C1

KIT, tilt angle breather, consists of (1) breather cap (NSS), (1) capscrew (NSS), (1) gasket (NSS), (1) plate, valve tappet inspection (NSS) service packages

1шт.

Выбрано товаров: 10
