Запчасти Case IH DG4D (K-03) - SERVICE ENGINES & SERVICE PACKAGES

69000C91

COMPLETE SERVICE ENGINE, 3200A loaders, consists of all engine parts except muffler and exhaust pipe

1шт.

69560C91

COMPLETE SERVICE ENGINE, 3200B loaders, consists of all engine parts except muffler and exhaust pipe

1шт.

70029C91

KIT

PACKAGE, points and condenser, consists of (1) arm, breaker (NSS), (1) bracket, contact (NSS), (1) wick, cam felt (NSS), (1) screw (NSS), (1) gasket (NSS), (1) gasket (NSS), (1) condenser & bracket (NSS) service packages

1шт.

70030C91

PACKAGE, magneto overhaul

1шт.

Consists of (1) gasket, flane (NSS), (1) breaker arm & support assy (NSS), (1) ring, snap (NSS), (1) gasket, cap (NSS), (1) gasket, frame (NSS), (1) ring, snap (NSS), (2) screw (NSS), (2) lock washer (NSS), (4) screw (NSS), (1) washer (NSS), (1) seal (NSS), (1) condenser & bracket (NSS), (1) bearing (NSS)

1шт.

69030C1

PACKAGE, carburetor repair

1шт.

Consists of (1) needle & seat (NSS), (1) gasket, flange (NSS), (2) washer (NSS), (2) retainer (NSS), (2) packing (NSS), (1) plug (NSS), (1) float (NSS), (1) washer (NSS), (1) washer (NSS), (1) gasket, flange (NSS), (2) retainer (NSS), (1) gasket, body (NSS), (1) plug (NSS), (1) screw (NSS), (2) packing (NSS), (1) washer (NSS), (1) washer (NSS)

1шт.

70035C91

PACKAGE, fuel pump repair

1шт.

Consists of (1) diaphragm (NSS), (1) gasket, cover (NSS), (2) valve & cage assy (NSS), (2) gasket, valve & cage (NSS), (1) bushing (NSS), (1) gasket, mounting (NSS), (1) gasket, diaphragm (NSS), (1) spring (NSS), (1) spring (NSS), (1) pin (NSS)

1шт.

71009C1

KIT

PACKAGE, fuel strainer repair, consists of (1) bowl, glass (NSS), (1) gasket, bowl (NSS), (1) filter (NSS) service packages

1шт.

70320C1

PACKAGE, valve grinding gasket, consists of the following gaskets (6) manifold (NSS), (4) valve inspection cover (NSS), (2) cylinder head (NSS) service packages

1шт.

69361C91

PACKAGE, gasket, 3200A loaders

1шт.

Consists of the following gaskets (4) manifold (NSS), (6) manifold insert (NSS), (1) carburetor (NSS), (1) fuel pump adapter (NSS), (1) fuel pump (NSS), (1) oil filter (NSS), (4) valve inspection cover (NSS), (1) magneto (NSS), (3) main bearing, .003, (NSS), (3) main bearing, .006, (NSS), (2) governor housing (NSS), (2) cylinder base (NSS), (1) gear cover (NSS), (1) crankcase (NSS), (1) bottom cover (NSS), (2) cylinder head (NSS)

1шт.

71711C1

PACKAGE, gasket, 3200B loaders

1шт.

Consists of the following gaskets (6) manifold (NSS), (1) carburetor (NSS), (1) fuel pump adapter (NSS), (1) oil filter (NSS), (4) valve inspection cover (NSS), (3) main bearing, .003, (NSS), (3) main bearing, .006 (NSS), (2) governor housing (NSS), (2) cylinder base (NSS), (1) gear cover (NSS), (1) crankcase (NSS), (2) cylinder head (NSS)

1шт.

407487R1

SET

universal spark plug wire, service packages

1шт.

407487R1GV

SET

Value, Package, Ignition Cable

1шт.

71602C1

KIT, tilt angle breather, consists of (1) cap (NSS), (1) washer (NSS), (1) gasket (NSS), (1) plate (NSS), (1) capscrew (NSS) service packages

1шт.
