(C-40[A]) - MUFFLER AND EXHAUST PIPE, 403 HILLSIDE COMBINES WITH SERIAL NO. 5001 AND ABOVE

Запчасти Case IH C-282 (C-40[A]) - MUFFLER AND EXHAUST PIPE, 403 HILLSIDE COMBINES WITH SERIAL NO. 5001 AND ABOVE

Схема запчастей Case IH C-282 - (C-40[A]) - MUFFLER AND EXHAUST PIPE, 403 HILLSIDE COMBINES WITH SERIAL NO. 5001 AND ABOVE
3
1
4
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

321575R91

CAP

ASSY, exhaust

1шт.

2

384345R92

MUFFLER

exhaust

1шт.

2

384345R92GV

MUFFLER

Value, Muffler

1шт.

3

384402R1

FASTENER

CLAMP, exhaust muffler

1шт.

102635

NUT,3/8"-16, G5

1шт.

179842

SPACER

3/8 x 1-3/8 cap screw

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

4

668531R1

PIPE, exhaust

1шт.

Выбрано товаров: 8
