Запчасти Case IH C-282 (C-09) - FAN BLADES AND SPACER, BELTS

1

380597R91

FAN

BLADE ASSY, fan

1шт.

179809

BOLT,Hex, 1/4" - 20 x 3", Gr 5

4шт.

80682

LOCK WASHER,1/4"

Washer, Lock, 1/4"

4шт.

2

Not used in this application

1шт.

3

SPACER, fan, on orders for 316476R1 furnish two 296645C1

1шт.

3

296645C1

SPACER

fan

2шт.

379629R1

V-BELT,0.50" W x 28.50" L

Fan drive 0.50" W x 28.50" L

1шт.

406617R1

BELT, water pump and alternator, generator, will work for 393415R1

1шт.

403617R1

V-BELT,0.50" W

Water pump and generator, will work for 393415R1 0.50" W

1шт.
