Запчасти Case IH C-221 (A-09) - CRANKCASE FRONT COVER AND IDLER GEAR

1

404724R21

COVER

ASSEMBLY, crankcase front

1шт.

179892

BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 5

1/2-13 x 2-3/4 hex-hd cap screw

6шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

6шт.

2

367572R1

INDICATOR

POINTER, timing

1шт.

3

391976R91

OIL SEAL

crankshaft oil

1шт.

4

367580R11

HUB

SHAFT ASSEMBLY, idler gear, engines w/serial no. 83736 and below

1шт.

141150

3/16 x 7/16 dowel

1шт.

179890

LATCH

SCREW, 1/2-13 x 2-1/4 hex-hd cap

1шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

4

530973R1

HOUSING

HUB, idler gear, engines w/serial no. 83737 and above

1шт.

413-828

BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5

1шт.

615090R1

WASHER

17/32 x 2 x 11 ga

1шт.

5

367578R1

BUSHING

idler gear, engines w/serial no. 83736 and below

1шт.

5

398034R1

BUSHING

idler gear, engines w/serial no. 83737 and above

1шт.

6

367577R11

PINION

GEAR ASSEMBLY, idler, engines w/serial no. 83736 and below

1шт.

6

398032R1

PINION

GEAR ASSEMBLY, idler, engines w/serial no. 83737 and above

1шт.

7

367574R1

GASKET

crankcase front cover

1шт.

8

367524R2

PLATE, crankcase front

1шт.

179838

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd

3/8-16 x 7/8 hex-hd cap

6шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

6шт.

9

398024R1

GASKET

crankcase front plate, will work for 367570R1

1шт.

1

369984R1

GASKET

crankcase pan

1шт.

2

396837R1

SUPPORT, throttle control rear bracket

1шт.

179818

BOLT,Hex, 5/16" - 18 x 1", Gr 5

2шт.

3

601380C11

OIL RESERVOIR

PAN ASSY, crankcase oil

1шт.

444630

PLUG,Hex Hd, 1/2"-14

1/2-14 hex-hd pipe

1шт.

179816

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

23шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

20шт.

95-11034

WASHER,1/4"

11/32 x 11/16 x .065

5шт.

4

119101

CAP,1/2" NPT

oil drain pipe

1шт.

5

628086R91

FITTING ASSY, oil drain

1шт.

6

628091R1

CLAMP, oil drain hose

2шт.

7

628089R1

HOSE, oil drain

1шт.

8

628087R1

PIPE, oil pan drain

1шт.
