Запчасти Case IH C-175 (F-03[A]) - SERVICE PACKAGES

398178R92

GASKET

PACKAGE, crankcase gasket service, consists of Ref. 1 - 16

1шт.

1

397968R1

GASKET

water pump plate

1шт.

2

398024R1

GASKET

crankcase front plate

1шт.

3

398085R1

GASKET

crankcase front cover

1шт.

4

310665R1

PLUG

rear bearing cap filler

2шт.

5

398031R2

GASKET

crankcase oil pan

1шт.

6

398040R2

GASKET

valve push rod cover

1шт.

7

367669R1

GASKET

governor housing

1шт.

8

353936R2

GASKET

distributor

1шт.

9

69607R1

GASKET

oil pump cover

2шт.

10

398079R1

GASKET

oil filter base

1шт.

11

69674R1

GASKET

water pump plate

1шт.

12

400315R1

GASKET

crankcase front cover

1шт.

13

405858R1

GASKET

crankcase oil pan

1шт.

14

398496R1

GASKET, fuel pump opening

1шт.

15

3405H

GASKET

crankcase oil pan drain plug

1шт.

16

399128R1

GASKET

oil pressure relief valve

1шт.

398177R96

GASKET KIT

PACKAGE, valve grinding gasket service, consists of Ref. 17 - 28

1шт.

17

530681R1

GASKET

carburetor

1шт.

18

397971R1

GASKET

water outlet elbow

1шт.

19

398066R4

GASKET

cylinder head

1шт.

20

398068R3

GASKET

valve cover

1шт.

21

164420R1

GROMMET

valve cover

3шт.

22

530682R1

MANIFOLD GASKET

intake to exhaust manifold

1шт.

23

866834R1

BAFFLE

SEAL, intake valve stem oil

8шт.

24

535166R1

RUBBER SEAL

intake valve stem

4шт.

25

397966R1

GASKET

water pump body

1шт.

26

22227R1

SET SCREW,Hex Soc, 3/8"-16 x 3/8"

O-RING, 1-7/16 x 1-5/8 x 3/32

1шт.

27

402928R1

SEAL

water by-pass

1шт.

28

69676R1

GASKET

water pump body

1шт.

386010R91

KIT

PACKAGE, governor overhaul service, consists of Ref. 29 - 43

1шт.

29

172530

PLUG,Exp, 11/16"

governor housing

1шт.

30

369593R1

BUSHING

governor

1шт.

31

369594R1

BUSHING

governor

2шт.

32

361123R91

OIL SEAL

OIL SEAL, governor rockshaft

1шт.

33

ST552

BALL BEARING,12mm ID x 37mm OD x 12mm W

BEARING, governor shaft ball

1шт.

34

281907C1

SNAP RING,1.438", Int, #143

Ring, Snap, , governor shaft brg 1.438", Int, #143

1шт.

35

367741R1

WEIGHT

governor

2шт.

36

17053R1

LOCK PIN,Sl Spring, 1/4" x 1 3/8"

PIN, , ESNA 1/4" x 1 3/8", Slotted

2шт.

37

387878R1

SLEEVE

governor thrust

1шт.

38

367656R12

ROCKSHAFT

LEVER AND ROCKSHAFT ASSY

1шт.

39

368938R1

SET SCREW,Hdls Hex Skt, 1/4" - 28 x 5/16", Cup Pt

governor thrust fork set

1шт.

40

367653R1

FORK

governor thrust

1шт.

41

374795R1

VALVE SPRING

SPRING, bumper

1шт.

42

393405R91

THRUST BEARING,11.07mm ID x 25.4mm OD x 11.13mm W

governor thrust ball

1шт.

43

367669R1

GASKET

governor housing

1шт.

374544R94

KIT

PACKAGE, water pump service, used w/water pump 601816C92, consists of Ref. 44 - 52

1шт.

44

387931R1

TORQ CONV IMPELLER

IMPELLER, water pump

1шт.

45

684432C1

SEAT/SLOT

RETAINER & SEAL ASSY, water pump

1шт.

46

73296R93

SEAL

ASSY, water pump

1шт.

47

376602R91

BEARING ASSY,30mm OD x 110.69mm L

SHAFT & BRG. ASSY, water pump with slinger

1шт.

PER JOHN C., P/N 376602R91 NO LONGER COMES WITH SLINGER. SLINGER P/N IS 151207R1. BJR

1шт.

48

71351R1

SLINGER

water pump

1шт.

49

102069H

RING

RETAINER, bearing

1шт.

50

69674R1

GASKET

water pump plate

1шт.

51

69676R1

GASKET

water pump

1шт.

52

327316R1

SNAP RING,1.188", Int, #118

Ring, Snap, , brg 1.188", Int, #118

1шт.

398179R93

PACKAGE

water pump service, used w/water pump 400677R92, consists of Ref. 53 - 59

1шт.

53

73296R93

SEAL

ASSY, water pump

1шт.

54

367689R1

IMPELLER

water pump

1шт.

55

369147R91

SHAFT

AND BEARING W/SLINGER, water pump

1шт.

56

71351R1

SLINGER

water pump

1шт.

57

102069H

RING

front snap

1шт.

58

397968R1

GASKET

water pump plate

1шт.

59

397966R1

GASKET

water pump body

1шт.

405924R91

KIT

PACKAGE, carburetor overhaul, used w/carburetor 400348R91, 404731R91 and 405873R92, consists of Ref. 60 - 70

1шт.

60

400429R93

PACKAGE

carburetor gaskets and seal

1шт.

61

400410R91

SHAFT ASSY, throttle

1шт.

62

131979

SCREW,Sl Fil Hd, #8 - 32 x 3/4"

throttle stop

1шт.

63

69953D

SPRING

throttle stop screw

1шт.

64

454979

SCREW, throttle and choke plate

4шт.

65

69923D

SCREW

idle adjusting needle

1шт.

66

69954D

SPRING

idle adjusting needle screw

1шт.

67

405920R1

PLUG

throttle shaft cup

1шт.

68

381949R1

CUP

PLUG, throttle shaft cup

1шт.

69

381963R1

AXLE

float

1шт.

70

392069R91

VALVE

AND SEAT ASSY, float

1шт.

537006R91

KIT

PACKAGE, carburetor overhaul, used w/carburetor 405688R91, consists of Ref. 71 - 79

1шт.

71

537007R91

KIT

PACKAGE, carburetor gasket and seal

1шт.

72

537008R91

SHAFT

AND LEVER ASSY, throttle

1шт.

73

19509R1

SCREW, throttle stop

1шт.

74

17164R1

LOCK PIN,3/32" x 7/16", Slotted

PIN, , Throttle lever 3/32" x 7/16", Slotted

1шт.

75

PLUG, throttle shaft hole

1шт.

76

537009R1

ADJUSTMENT SCREW

SCREW, idle adjusting needle

1шт.

77

454415

SCREW, throttle and choke plate

4шт.

78

381030R1

AXLE

float

1шт.

79

390873R91

VALVE

NEEDLE VALVE AND SEAT ASSY, fuel jet, idle

1шт.

400429R93

PACKAGE

carburetor gasket, used w/carburetor 400348R91, 404731R91 and 405873R92

2шт.

Consists of gasket, nozzle, plug lower, gasket, float valve seat, gasket, nozzle, gasket, throttle body to bowl, gasket, solenoid, seal, choke shaft, seal, throttle shaft, seal, nozzle plug upper

1шт.

537007R91

KIT

PACKAGE, carburetor gasket, used w/carburetor 405688R91

1шт.

Consists of gasket, bowl to body, gasket, main discharge nozzle & jet, gasket, fuel needle valve seat, seal, throttle shaft, retainer, throttle shaft seal, seal, choke shaft, washer, choke shaft seal retainer

1шт.

407487R1

SET

PACKAGE, ignition cable service, engines w/serial number 5811 and below, consists of (4) spark plug cables (NSS), (1) coil to distributor cap cable (NSS), (4) nipples (NSS), (6) terminals (NSS), (1) strap, lock (NSS)

1шт.

407487R1GV

SET

Value, Package, Ignition Cable

1шт.

70219C91

PACKAGE

ignition cable service, engines w/serial number 5812 and above, consists of (4) spark plug cables (NSS), (1) coil to distributor cable (NSS), (1) retainer 536582R1, (2) retainer 531981R1, (4) insulator 371430R1

1шт.
