Запчасти Case IH C-157 (J-03[A]) - SERVICE PACKAGES

Схема запчастей Case IH C-157 - (J-03[A]) - SERVICE PACKAGES

Артикул

Название

Примечание

Количество

398177R96

GASKET KIT

PACKAGE, valve grinding gasket service, consists of Ref. 1 - 12

1шт.

1

530681R1

GASKET

carburetor

1шт.

2

397971R1

GASKET

water outlet elbow

1шт.

3

398066R4

GASKET

cylinder head

1шт.

4

398068R3

GASKET

valve cover

1шт.

5

164420R1

GROMMET

valve cover

3шт.

6

530682R1

MANIFOLD GASKET

intake to exhaust manifold

1шт.

7

866834R1

BAFFLE

SEAL, intake valve stem oil

8шт.

8

535166R1

RUBBER SEAL

intake valve stem

4шт.

9

397966R1

GASKET

water pump body

1шт.

10

22277R1

O-RING,0.103" Thk x 1.424" ID, -127, Cl 5, 75 Duro

1-7/16 x 1-5/8 x 3/32

1шт.

11

402928R1

SEAL

water by-pass

1шт.

12

69676R1

GASKET

water pump body

1шт.

398178R92

GASKET

PACKAGE, crankcase gasket service, consists of Ref. 13 - 31

1шт.

13

397968R1

GASKET

water pump plate

1шт.

14

398024R1

GASKET

crankcase front plate

1шт.

15

398085R1

GASKET

crankcase front cover

1шт.

16

310665R1

PLUG

rear bearing cap filler

2шт.

17

398031R2

GASKET

crankcase oil pan

1шт.

18

398040R2

GASKET

valve push rod cover

1шт.

19

367669R1

GASKET

governor housing

1шт.

20

353936R2

GASKET

distributor

1шт.

21

69607R1

GASKET

oil pump cover

1шт.

22

398901R1

GASKET,0.89" ID x 1.20" OD x 0.094" Thk

oil filter base screw

1шт.

23

69674R1

GASKET

water pump plate

1шт.

24

400315R1

GASKET

crankcase front cover

1шт.

25

405858R1

GASKET

crankcase oil pan

1шт.

26

398079R1

GASKET

oil filter base

1шт.

27

375783R3

GASKET

breather pipe

1шт.

28

349363R1

FILTER CARTRIDGE

ELEMENT, breather

1шт.

29

532496R1

GASKET

fuel pump opening

1шт.

30

3405H

GASKET

crankcase oil pan drain plug

1шт.

31

399128R1

GASKET

oil pressure relief valve

1шт.

398179R93

PACKAGE

water pump service, consists of Ref. 32 - 38

1шт.

32

73296R93

SEAL

ASSY, water pump

1шт.

33

367689R1

IMPELLER

water pump

1шт.

34

369147R91

SHAFT

AND BEARING, w/slinger, water pump

1шт.

35

71351R1

SLINGER

water pump

1шт.

36

102069H

RING

front snap

1шт.

37

397368R1

GASKET, water pump plate

1шт.

38

397966R1

GASKET

water pump body

1шт.

386010R91

KIT

PACKAGE, governor overhaul service, consists of Ref. 39 - 54

1шт.

39

172530

PLUG,Exp, 11/16"

governor housing

1шт.

40

369593R1

BUSHING

governor

1шт.

41

369594R1

BUSHING

governor

2шт.

42

361123R91

OIL SEAL

OIL SEAL, governor rockshaft

1шт.

43

ST552

BALL BEARING,12mm ID x 37mm OD x 12mm W

BEARING, governor shaft ball

1шт.

44

373185R91

BEARING

governor shaft ball

1шт.

45

281907C1

SNAP RING,1.438", Int, #143

Ring, Snap, , governor shaft brg 1.438", Int, #143

1шт.

46

367741R1

WEIGHT

governor

2шт.

47

17053R1

LOCK PIN,Sl Spring, 1/4" x 1 3/8"

PIN, , ESNA 1/4" x 1 3/8", Slotted

2шт.

48

387878R1

SLEEVE

governor thrust

1шт.

49

367656R12

ROCKSHAFT

LEVER AND ROCKSHAFT ASSY

1шт.

50

368938R1

SET SCREW,Hdls Hex Skt, 1/4" - 28 x 5/16", Cup Pt

governor thrust fork set

1шт.

51

367653R1

FORK

governor thrust

1шт.

52

374795R1

VALVE SPRING

SPRING, bumper

1шт.

53

393405R91

THRUST BEARING,11.07mm ID x 25.4mm OD x 11.13mm W

governor thrust ball

1шт.

54

367669R1

GASKET

governor housing

1шт.

407487R1

SET

PACKAGE, ignition cable service, engines w/serial number 8406 and below, consists of (4) spark plug cables (NSS), (1) coil to distributor cap cable (NSS), (4) nipples (NSS), (6) terminals (NSS), (1) strap, lock (NSS)

1шт.

407487R1GV

SET

Value, Package, Ignition Cable

1шт.

70219C91

PACKAGE

S, ignition cable service, engines w/serial number 8407 and above, (4) spark plug cables (NSS), (1) coil to distributor calbe (NSS), (1) retainer 536582R1, (2) retainer 531981R1, (4) insulator 371430R1

1шт.

Выбрано товаров: 61
