Запчасти Case IH C-146 (D-02[A]) - SERVICE PACKAGES

395168R91

PACKAGE, governor assembly service, 660, 770 and 780 hi-clear sprayers, consists of Ref. 1 - 41

1шт.

1

43481D

BEARING ASSY,12.8mm ID x 23.81mm OD x 10.19mm W

BALL BEARING, governor thrust

1шт.

2

31804DA

BODY

governor bumper spring

1шт.

3

367711R1

FORK

governor rockshaft

1шт.

4

45875D

GASKET

governor housing

1шт.

5

6340DBX

HOUSING

ASSEMBLY, governor

1шт.

6

46947DAXB

LEVER

AND SHAFT, governor

1шт.

7

51491DB

LEVER

governor spring

1шт.

8

114494

NUT,Jam, 3/8"-24, G5

1шт.

9

114503

JAM NUT,Jam, 3/8"-16, G5

1шт.

10

129-531

NUT,Crown, 7/16"-14

7/16-20 NF low crown

1шт.

11

425-157

JAM NUT,Jam, 7/16"-20, G5

1шт.

12

149345R91

OIL SEAL

SEAL, governor speed change shaft oil

1шт.

13

395182R91

PACKAGE, governor overhaul service

1шт.

14

46924D

PIN

governor weight

2шт.

15

49219DA

AXLE PIN,4.78mm OD x 26.99mm L

PIN, governor shaft bumper

1шт.

16

108628

PIN

1/16 X 7/8 cot.

2шт.

17

375778R11

GEAR

PINION ASSY, ignition unit and governor, 33 teeth

1шт.

18

43483D

SEAL RETAINER

RETAINER, governor rockshaft seal

1шт.

19

367709R11

ROCKSHAFT

ASSY, governor

1шт.

20

179821

BOLT,Hex, 5/16" - 18 x 1 3/8", Gr 5

1шт.

21

13-536

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

2шт.

22

179829

BOLT,Hex, 5/16" - 18 x 2 3/4", Gr 5

2шт.

23

131970

SCREW,Sl Fil Hd, #8 - 32 x 1/2"

no. 8 x 1/2 slt-rd-hd mach

2шт.

24

43482D

SEAL,9.53mm ID x 18.26mm OD x 5.56mm Thk

SEAL, governor rockshaft

1шт.

25

49325D

BUSHING

SLEEVE, governor thrust, or

1шт.

26

363866R1

BUSHING,12.83mm ID x 23.81mm OD x 27.51mm L

SLEEVE, governor thrust

1шт.

27

28078D

VALVE SPRING

SPRING, governor bumper

1шт.

28

49218DA

SPRING

governor bumper

1шт.

29

364113R1

SPRING

governor

1шт.

30

357432R3

BOLT

STOP, governor speed change lever

1шт.

31

492-11008

LOCK WASHER,#8

Washer, Lock, #8

2шт.

32

93-41039

LOCK WASHER,Ext Tooth, 3/8"

WASHER, 3/8 ext-tooth lock

1шт.

33

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

5шт.

34

151341R1

WASHER

governor spring lever, or

2шт.

35

17081H

WASHER

33/64 x 3/4 x 16 ga

2шт.

36

374710R1

WEIGHT

governor

2шт.

37

46939D

BUSHING,9.59mm ID x 19.13mm OD x 11.11mm L

governor rockshaft

1шт.

38

45753D

BEARING, NEEDLE,Needle, 9.51mm ID x 15.89mm OD x 12.7mm W

BEARING, governor rockshaft

2шт.

39

172531

PLUG,Exp, 3/4"

governor housing

1шт.

40

49220D

STOP

PIN, governor shaft stop

1шт.

41

46942D

AXLE PIN,5.56mm OD x 18.26mm L

PIN, governor rockshaft lever retainer

1шт.

381738R91

GASKET

SET, crankcase, consists of Ref. 42 - 58

1шт.

42

375783R1

GASKET

BREATHER PIPE FLANGE GASKET

1шт.

43

46179DC

GASKET

CRANKCASE FRONT COVER GASKET

1шт.

44

43445DA

PAD

CRANKSHAFT OIL SEAL RETAINER PLATE FELT

4шт.

45

43446DA

GASKET,1.29mm Thk

CRANKSHAFT OIL SEAL RETAINER PLATE GASKET

4шт.

46

378040R91

PACKING RING

CRANKSHAFT REAR OIL SEAL

1шт.

47

377997R1

GASKET

CRANKSHAFT REAR OIL SEAL RETAINER GASKET

1шт.

48

46168DB

GASKET

DISTRIBUTOR DRIVE HOUSING GASKET

1шт.

49

49124D

GASKET

FUEL PUMP GASKET

1шт.

50

45875D

GASKET

GOVERNOR HOUSING GASKET

1шт.

51

43482D

SEAL,9.53mm ID x 18.26mm OD x 5.56mm Thk

GOVERNOR ROCKSHAFT FELT SEAL

1шт.

52

149345R91

OIL SEAL

GOVERNOR SPEED CHANGE LEVER SHAFT OIL SEAL

1шт.

53

13728D

GASKET

OIL FILTER CASE GASKET

1шт.

54

43458DB

GASKET

OIL PAN GASKET

1шт.

55

375786R1

GASKET

OIL PUMP BODY COVER GASKET

2шт.

56

367687R1

GASKET

WATER PUMP BODY GASKET

1шт.

57

375743R1

GASKET

WATER PUMP BODY GASKET

1шт.

58

375745R1

GASKET

WATER PUMP PLATE GASKET

1шт.

395182R91

PACKAGE, governor overhaul service, 660, 770 and 780 hi-clear sprayers, consists of Ref. 59 - 84

1шт.

59

43481D

BEARING ASSY,12.8mm ID x 23.81mm OD x 10.19mm W

BALL BEARING, governor thrust

1шт.

60

45753D

BEARING, NEEDLE,Needle, 9.51mm ID x 15.89mm OD x 12.7mm W

BEARING, governor rockshaft needle

2шт.

61

46939D

BUSHING,9.59mm ID x 19.13mm OD x 11.11mm L

governor rockshaft

1шт.

62

367711R1

FORK

governor rockshaft

1шт.

63

45875D

GASKET

governor housing

1шт.

64

46947DAXB

LEVER

AND SHAFT, governor

1шт.

65

51491DB

LEVER

governor spring

1шт.

66

149345R91

OIL SEAL

SEAL, governor speed change shaft oil

1шт.

67

46924D

PIN

governor weight

2шт.

68

46942D

AXLE PIN,5.56mm OD x 18.26mm L

PIN, governor rockshaft lever retainer

1шт.

69

49219DA

AXLE PIN,4.78mm OD x 26.99mm L

PIN, governor shaft bumper

1шт.

70

108628

PIN

1/16 x 7/8 cot.

2шт.

71

172531

PLUG,Exp, 3/4"

3/4 expansion

1шт.

72

43483D

SEAL RETAINER

RETAINER, governor rockshaft seal

1шт.

73

367709R11

ROCKSHAFT

ASSY, governor

1шт.

74

179827

FRONT AXLE

2шт.

75

43482D

SEAL,9.53mm ID x 18.26mm OD x 5.56mm Thk

SEAL, governor rockshaft

1шт.

76

49325D

BUSHING

SLEEVE, governor, or

1шт.

77

363866R1

BUSHING,12.83mm ID x 23.81mm OD x 27.51mm L

SLEEVE, governor thrust

1шт.

78

28078D

VALVE SPRING

SPRING, governor bumper

1шт.

79

49218DA

SPRING

governor bumper

1шт.

80

364113R1

SPRING

governor

1шт.

81

357432R3

BOLT

STOP, governor speed change lever

1шт.

82

151341R1

WASHER

governor spring lever, or

2шт.

83

17081H

WASHER

33/64 x 3/4 x 16 ga

2шт.

84

374710R1

WEIGHT

governor

2шт.

379620R92

GASKET

PACKAGE, crankcase front cover seal and gasket, consists of Ref. 85 - 90

1шт.

85

46179DC

GASKET

CRANKCASE FRONT COVER GASKET

1шт.

86

43294D

GASKET

FAN BRACKET GASKET

1шт.

87

378193R91

SEAL

CRANKCASE FRONT COVER OIL SEAL

1шт.

88

45875D

GASKET

GOVERNOR HOUSING GASKET

1шт.

89

68104C1

GASKET

WATER PUMP GASKET

1шт.

90

375745R1

GASKET

WATER PUMP PLATE GASKET

1шт.

375866R95

PACKAGE

GASKET SET, valve grinding, consists of Ref. 91 - 98

1шт.

91

382116R1

GASKET

CARBURETOR GASKET

1шт.

92

530681R1

GASKET

CARBURETOR TO MANIFOLD GASKET

1шт.

93

383525R3

GASKET

CYLINDER HEAD GASKET

1шт.

94

352014R3

GASKET

EXHAUST AND INTAKE MANIFOLD GASKET

2шт.

95

43294D

GASKET

FAN BRACKET GASKET

1шт.

96

43378DD

GASKET

VALVE HOUSING GASKET

1шт.

97

62866D

WASHER,5/64" Thk x 13/32" ID

VALVE HOUSING STUD NUT, OR

1шт.

98

357374R1

O-RING,0.07" Thk x 0.364" ID, -12, Cl 5, 75 Duro

VALVE HOUSING STUD NUT

1шт.

407487R1

SET

PACKAGE, ignition cable service, engines w/serial number 17211 and below, consists of (4) spark plug cables (NSS), (1) coil to distributor cable (NSS), (4) nipples (NSS), (6) terminals (NSS), (1) strap, lock (NSS)

1шт.

407487R1GV

SET

Value, Package, Ignition Cable

1шт.

70218C91

PACKAGE

ignition cable service, engines w/serial number 17212 and above, consists of (4) spark plug cables (NSS), (1) coil to distributor cable (NSS), (1) strap, lock (NSS)

1шт.

391020R93

PACKAGE, governor assy service, 424 tractors and 500 crawler tractors, consists of Ref. 99 - 141

1шт.

99

375778R11

GEAR

PINION ASSY, magneto and governor

1шт.

100

49218DA

SPRING

governor shaft bumper

1шт.

101

49219DA

AXLE PIN,4.78mm OD x 26.99mm L

PIN, governor shaft bumper

1шт.

102

49325D

BUSHING

SLEEVE, governor thrust, or

1шт.

103

363866R1

BUSHING,12.83mm ID x 23.81mm OD x 27.51mm L

SLEEVE GOVERNOR THRUST

1шт.

104

46924D

PIN

governor weight

2шт.

105

108628

PIN

1/16 x 7/8 cot.

2шт.

106

393750R1

WEIGHT

governor

2шт.

107

43481D

BEARING ASSY,12.8mm ID x 23.81mm OD x 10.19mm W

BEARING, governor thrust ball

1шт.

108

6340DBX

HOUSING

ASSY, governor

1шт.

109

179821

BOLT,Hex, 5/16" - 18 x 1 3/8", Gr 5

1шт.

110

179827

FRONT AXLE

1шт.

111

179829

BOLT,Hex, 5/16" - 18 x 2 3/4", Gr 5

3шт.

112

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

5шт.

113

46939D

BUSHING,9.59mm ID x 19.13mm OD x 11.11mm L

governor rockshaft

1шт.

114

45753D

BEARING, NEEDLE,Needle, 9.51mm ID x 15.89mm OD x 12.7mm W

BEARING, governor

1шт.

115

45753D

BEARING, NEEDLE,Needle, 9.51mm ID x 15.89mm OD x 12.7mm W

BEARING, governor rockshaft

2шт.

116

172531

PLUG,Exp, 3/4"

governor housing

1шт.

117

49220D

STOP

PIN, governor shaft stop

1шт.

118

46942D

AXLE PIN,5.56mm OD x 18.26mm L

PIN, governor rockshaft lever retainer

1шт.

119

45875D

GASKET

governor housing

1шт.

120

28078D

VALVE SPRING

SPRING, governor bumper

1шт.

121

31804DA

BODY

governor bumper spring

1шт.

122

425-157

JAM NUT,Jam, 7/16"-20, G5

1шт.

123

129-531

NUT,Crown, 7/16"-14

7/16-20 low crown

1шт.

124

367709R11

ROCKSHAFT

ASSY, governor

1шт.

125

43482D

SEAL,9.53mm ID x 18.26mm OD x 5.56mm Thk

SEAL, governor rockshaft

1шт.

126

43483D

SEAL RETAINER

RETAINER, governor rockshaft seal

1шт.

127

367711R1

FORK

governor rockshaft

1шт.

128

131970

SCREW,Sl Fil Hd, #8 - 32 x 1/2"

8-32 x 1/2 rd-hd-slt mach

2шт.

129

492-11008

LOCK WASHER,#8

Washer, Lock, #8

2шт.

130

46947DAXB

LEVER

ASSY, governor speed change

1шт.

131

114494

NUT,Jam, 3/8"-24, G5

1шт.

132

93-41039

LOCK WASHER,Ext Tooth, 3/8"

WASHER, governor speed change lever lock

1шт.

133

149345R91

OIL SEAL

OIL SEAL, governor speed change shaft

1шт.

134

51491DB

LEVER

governor spring

1шт.

135

151341R1

WASHER

governor spring lever, or

2шт.

136

17084H

WASHER, 33/64 x 3/4 x 16 ga

2шт.

137

357432R3

BOLT

STOP, governor speed change lever

1шт.

138

114503

JAM NUT,Jam, 3/8"-16, G5

1шт.

139

389452R2

SPRING

governor high speed

1шт.

140

389451R2

SPRING

governor low speed

1шт.

141

391021R93

PACKAGE

governor overhaul service

1шт.

391028R92

STRIPPER PACKAGE

PACKAGE, water pump service, consists of Ref. 142 - 148

1шт.

142

375745R1

GASKET

water pump plate

1шт.

143

367687R1

GASKET

water pump body

1шт.

144

367689R1

IMPELLER

water pump

1шт.

145

73296R93

SEAL

ASSEMBLY, water pump

1шт.

146

ST644

SHAFT

BEARING WITH SHAFT, water pump

1шт.

147

102069H

RING

front snap

1шт.

148

368501R2

HUB CAP

HUB, pulley

1шт.

379619R91

PACKAGE

rear main bearing seal and gasket, consists of Ref. 149 - 152

1шт.

149

43446DA

GASKET,1.29mm Thk

2шт.

150

377997R1

GASKET

1шт.

151

378040R91

PACKING RING

OIL SEAL

1шт.

152

43445DA

PAD

PLUG

2шт.

391021R93

PACKAGE

governor overhaul service, 424 tractors and 500 crawler tractors, consists of Ref. 153 - 221

1шт.

153

46939D

BUSHING,9.59mm ID x 19.13mm OD x 11.11mm L

governor rockshaft

1шт.

154

45753D

BEARING, NEEDLE,Needle, 9.51mm ID x 15.89mm OD x 12.7mm W

BEARING, governor rockshaft

2шт.

155

172531

PLUG,Exp, 3/4"

governor housing

1шт.

156

49218DA

SPRING

governor shaft bumper

1шт.

157

46942D

AXLE PIN,5.56mm OD x 18.26mm L

PIN, governor rockshaft lever retainer

1шт.

158

45875D

GASKET

governor housing

1шт.

159

179827

FRONT AXLE

Governor housing Hex, 5/16"-18 x 2 1/4", G5

1шт.

160

28078D

VALVE SPRING

SPRING, governor bumper

1шт.

161

43482D

SEAL,9.53mm ID x 18.26mm OD x 5.56mm Thk

SEAL, governor rockshaft

1шт.

162

43483D

SEAL RETAINER

RETAINER, governor rockshaft seal

1шт.

163

367711R1

FORK

governor rockshaft

1шт.

164

46947DAXB

LEVER

ASSY, governor speed change

1шт.

165

149345R91

OIL SEAL

OIL SEAL, governor speed change shaft

1шт.

166

51491DB

LEVER

governor spring

1шт.

167

151341R1

WASHER

governor spring lever, or

2шт.

168

17084H

WASHER, 33/64 x 3/4 x 16 ga

2шт.

169

357432R3

BOLT

STOP, governor speed change lever

1шт.

170

389452R2

SPRING

governor high speed

1шт.

171

389451R2

SPRING

governor low speed

1шт.

172

49219DA

AXLE PIN,4.78mm OD x 26.99mm L

PIN, governor shaft bumper

1шт.

173

49325D

BUSHING

SLEEVE, governor thrust, or

1шт.

174

363866R1

BUSHING,12.83mm ID x 23.81mm OD x 27.51mm L

SLEEVE GOVERNOR THRUST

1шт.

175

46924D

PIN

governor weight

2шт.

176

108628

PIN

1/16 x 7/8 cot.

2шт.

177

393750R1

WEIGHT

governor

2шт.

178

43481D

BEARING ASSY,12.8mm ID x 23.81mm OD x 10.19mm W

BEARING, governor thrust ball

1шт.

179

367709R11

ROCKSHAFT

ASSY, governor

1шт.

180

405200R91

PACKAGE, governor assy

1шт.

181

375778R11

GEAR

PINION ASSY, magneto and governor

1шт.

182

49218DA

SPRING

governor shaft bumper

1шт.

183

49219DA

AXLE PIN,4.78mm OD x 26.99mm L

PIN, governor shaft bumper

1шт.

184

49325D

BUSHING

SLEEVE, governor thrust, or

1шт.

185

363866R1

BUSHING,12.83mm ID x 23.81mm OD x 27.51mm L

SLEEVER GOVERNOR THRUST

1шт.

186

46924D

PIN

governor weight

2шт.

187

108628

PIN

1/16 x 7/8 cot.

2шт.

188

351891R1

WEIGHT

governor

2шт.

189

43481D

BEARING ASSY,12.8mm ID x 23.81mm OD x 10.19mm W

BEARING, governor thrust ball

1шт.

190

6340DBX

HOUSING

ASSY, governor

1шт.

191

179821

BOLT,Hex, 5/16" - 18 x 1 3/8", Gr 5

1шт.

192

13-536

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

1шт.

193

179829

BOLT,Hex, 5/16" - 18 x 2 3/4", Gr 5

3шт.

194

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

5шт.

195

46939D

BUSHING,9.59mm ID x 19.13mm OD x 11.11mm L

governor rockshaft

1шт.

196

45753D

BEARING, NEEDLE,Needle, 9.51mm ID x 15.89mm OD x 12.7mm W

BEARING, governor rockshaft

2шт.

197

172531

PLUG,Exp, 3/4"

governor housing

1шт.

198

49220D

STOP

PIN, governor shaft stop

1шт.

199

46942D

AXLE PIN,5.56mm OD x 18.26mm L

PIN, governor rockshaft lever retainer

1шт.

200

45875D

GASKET

governor housing

1шт.

201

28078D

VALVE SPRING

SPRING, governor bumper

1шт.

202

31804DA

BODY

governor bumper spring

1шт.

203

425-157

JAM NUT,Jam, 7/16"-20, G5

1шт.

204

129-531

NUT,Crown, 7/16"-14

7/16-20 low crown

1шт.

205

367709R11

ROCKSHAFT

ASSY, governor

1шт.

206

43482D

SEAL,9.53mm ID x 18.26mm OD x 5.56mm Thk

SEAL, governor rockshaft

1шт.

207

43483D

SEAL RETAINER

RETAINER, governor rockshaft seal

1шт.

208

367711R1

FORK

governor rockshaft

1шт.

209

131970

SCREW,Sl Fil Hd, #8 - 32 x 1/2"

8-32 x 1/2 rd-hd slt mach

2шт.

210

492-11008

LOCK WASHER,#8

Washer, Lock, #8

2шт.

211

46947DAXB

LEVER

ASSY, governor speed change

1шт.

212

114494

NUT,Jam, 3/8"-24, G5

1шт.

213

93-41039

LOCK WASHER,Ext Tooth, 3/8"

WASHER, governor speed change lever lock

1шт.

214

149345R91

OIL SEAL

OIL SEAL, governor speed change shaft

1шт.

215

51491DB

LEVER

governor spring

1шт.

216

151341R1

WASHER

governor spring lever, or

2шт.

217

17081H

WASHER

33/64 x 3/4 x 16 ga

2шт.

218

357432R3

BOLT

STOP, governor speed change lever

1шт.

219

114503

JAM NUT,Jam, 3/8"-16, G5

1шт.

220

381242R1

SPRING

governor

1шт.

221

405201R91

PACKAGE, governor overhaul service

1шт.

405201R91

PACKAGE, governor overhaul service, 5000 crawler tractors, consists of Ref. 222 - 247

1шт.

222

46939D

BUSHING,9.59mm ID x 19.13mm OD x 11.11mm L

governor rockshaft

1шт.

223

45753D

BEARING, NEEDLE,Needle, 9.51mm ID x 15.89mm OD x 12.7mm W

BEARING, governor rockshaft

2шт.

224

172531

PLUG,Exp, 3/4"

governor housing

1шт.

225

49218DA

SPRING

governor shaft bumper

1шт.

226

46942D

AXLE PIN,5.56mm OD x 18.26mm L

PIN, governor rockshaft lever retainer

1шт.

227

45875

SPARE PART

GASKET, governor housing

1шт.

228

179827

FRONT AXLE

Governor housing Hex, 5/16"-18 x 2 1/4", G5

1шт.

229

28078D

VALVE SPRING

SPRING, governor bumper

1шт.

230

43482D

SEAL,9.53mm ID x 18.26mm OD x 5.56mm Thk

SEAL, governor rockshaft

1шт.

231

43483D

SEAL RETAINER

RETAINER, governor rockshaft seal

1шт.

232

367711R1

FORK

governor rockshaft

1шт.

233

46947DAXB

LEVER

ASSY, governor speed change

1шт.

234

149345R91

OIL SEAL

OIL SEAL, governor speed change shaft

1шт.

235

51491DB

LEVER

governor spring

1шт.

236

151341R1

WASHER

governor spring lever, or

2шт.

237

17081G

WASHER, 33/64 x 3/4 x 16 ga

2шт.

238

357432R3

BOLT

STOP, governor speed change lever

1шт.

239

381242R1

SPRING

governor

1шт.

240

49219DA

AXLE PIN,4.78mm OD x 26.99mm L

PIN, governor shaft bumper

1шт.

241

49325D

BUSHING

SLEEVER, governor thrust, or

1шт.

242

363866R1

BUSHING,12.83mm ID x 23.81mm OD x 27.51mm L

SLEEVE GOVERNOR THRUST

1шт.

243

49924D

GASKET

PIN, governor weight

2шт.

244

108628

PIN

1/16 x 7/8 cot.

2шт.

245

351891R1

WEIGHT

governor

2шт.

246

43481D

BEARING ASSY,12.8mm ID x 23.81mm OD x 10.19mm W

BEARING, governor thrust ball

1шт.

247

367709R11

ROCKSHAFT

ASSY, governor

1шт.

377577R91

PACKAGE, distributor shaft bushing, consists of (1) bushing 353921R1

1шт.
