Запчасти Case IH C-123 (B-14) - FAN BLADES AND SPACERS, BELTS

1

70214D

FAN

BLADE ASSY, fan, 100, 130 tractors and 57 twine or wire balers

1шт.

1007760BS

PULLEY

12-24 x 3/8 slt-rd-hd

8шт.

106498

LOCK WASHER,#12

Washer, Lock, #12

2шт.

1

377049R91

FAN

BLADE ASSY FAN, replaces 367682R91, 140 tractors and T-4 crawler tractors

1шт.

179791

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

Engines w/S/N 95963 and below Hex, 1/4"-20 x 1/2", G5, Full Thd

4шт.

181311

BOLT,Hex, 1/4" - 28 x 5/8", Gr 5

1/4-28 x 5/8 hex-hd cap, engines w/serial no. 95964 and above

4шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

4шт.

1

309077R91

FAN

BLADE ASSY, blower fan, T-4 crawler tractors

1шт.

179792

BOLT,Hex, 1/4" - 20 x 9/16"

1/4-20 x 9/16 hex-hd cap, engines w/serial no. 95963 and below

4шт.

181310

BOLT

1/4-28 x 9/16 hex-hd cap, engines w/serial no. 95964 and above

4шт.

2

(Not used this application)

1шт.

3

(Not used this application)

1шт.

60712D

V-BELT,0.66" W x 35.38" L

Fan, 100 and 130 tractors 0.66" W x 35.38" L

1шт.

368084R1

BELT

fan, heavy duty, 100, 130 tractors and 57 twine or wire balers

1шт.

367697R1

V-BELT,0.38" W x 42.00" L

Fan, Generator and water pump, Plain, Optional with 68386C1, 140 tractors and T-4 crawler tractors 0.38" W x 42.00" L

1шт.

68386C1

V-BELT,0.38" W x 42.75" L

Fan, Generator and Water Pump, Cog Type, Optional with 367697R1, 140 Tractors and T-4 Crawler Tractors 0.38" W x 42.75" L

1шт.
