Запчасти Case IH BC-144 (H-03) - COMPLETE SERVICE ENGINE & SERVICE PACKAGES

396802R91

COMPLETE SERVICE ENGINE, 3414 loader, 3414 dozer and 3444 tractrs w/flat type flywheel, consists of all engine parts except the following, alternator generator, fan belt, muffler and exhaust pipe

1шт.

396803R91

NO LONGER SERVICED

COMPLETE SERVICE ENGINE, 3414 loader, 3414 dozer and 3444 tractors w/pot type flywheel, consists of all engine parts except the following alternator generator, fan belt, muffler and exhaust pipe

1шт.

396816R91

COMPLETE SERVICE ENGINE, 7000 fork lift, consists of all engine parts except the following, alternator generator, fan belt, muffler and exhaust pipe

1шт.

3073817R91

SERVICE ENGINE SHORT BLOCK, 3414 loader, 3414 dozer and 3444 tractors w/flat type flywheel, consists of all engine parts except the following alternator generator, carburetor, fan belt, fuel pump, muffler and exhaust pipe

1шт.

3073818R91

SERVICE ENGINE SHORT BLOCK, 3414 loader, 3414 dozer and 3444 tractors w/pot type flywheel, consists of all engine parts except the following alternator generator, carburetor, fan belt, fuel pump, muffler and exhaust pipe

1шт.

3073815R91

SERVICE ENGINE SHORT BLOCK, 7000 fork lift, consists of all engine parts except the following alternator generator, carburetor, fan belt, fuel pump, muffler and exhaust pipe

1шт.

3044241R93

GASKET KIT

GASKET SET, crankcase, consists of Ref. 1 - 18

1шт.

1

3047295R1

CARBURETOR GASKET

1шт.

2

708285R1

GASKET

CRANKCASE FRONT COVER GASKET

1шт.

3

703840R1

GASKET

CRANKCASE PAN GASKET

1шт.

4

709903R1

GASKET

CRANKCASE FRONT PLATE GASKET

1шт.

5

3072092R91

OIL SEAL

CRANKSHAFT REAR OIL SEAL

1шт.

6

708907R1

GASKET

CRANKSHAFT REAR OIL SEAL RETAINER GASKET

1шт.

7

3045854R1

GASKET

CYLINDER HEAD GASKET

1шт.

8

3043370R1

GASKET

FUEL PUMP GASKET

1шт.

9

3061658R1

GASKET

FUEL PUMP GASKET

1шт.

10

3044211R1

GASKET

GOVERNOR HOUSING COVER GASKET

1шт.

11

3044212R1

GASKET

GOVERNOR HOUSING GASKET

1шт.

12

703851R1

GASKET

HYDRAULIC PUMP OPENING COVER GASKET

1шт.

13

3044210R1

GASKET

INTAKE AND EXHAUST MANIFOLD GASKET

2шт.

14

706592R1

GASKET

OIL FILTER BASE GASKET

1шт.

15

3405H

GASKET

OIL PAN DRAIN PLUG GASKET

1шт.

16

703815R1

GASKET

THERMOSTAT HOUSING GASKET

1шт.

17

703896R1

GASKET

VALVE COVER GASKET

1шт.

18

703816R1

GASKET

WATER PUMP GASKET

1шт.

3044209R92

GASKET KIT

GASKET SET, valve grinding, consists of Ref. 19 - 22

1шт.

19

3045854R1

GASKET

CYLINDER HEAD GASKET

1шт.

20

3044210R1

GASKET

INTAKE AND EXHAUST MANIFOLD GASKET

2шт.

21

703815R1

GASKET

THERMOSTAT HOUSING GASKET

1шт.

22

703896R1

GASKET

VALVE COVER GASKET

1шт.

3106564R91

SERVICE KIT

PACKAGE, water pump service, consists of Ref. 23 - 27

1шт.

23

704217R91

NO LONGER SERVICED

BEARING, water pump spindle

1шт.

24

703816R1

GASKET

water pump

1шт.

25

709909R2

TURBINE

IMPELLER, water pump

1шт.

26

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

water pump spindle

1шт.

27

703822R91

SEAL

water pump

1шт.

407487R1

SET

universal spark plug wire

1шт.

407487R1GV

SET

Value, Package, Ignition Cable

1шт.
