Запчасти Case IH V-800 (B-02) - BASIC SERVICE ENGINE / SKELETON SERVICE ENGINE / ENGINE PACKAGES

749850C91

BASIC ENGINE, renewed, 4568, 4586 and 4786 tractors, Consists of Ref. 1 -21

1шт.

1

NSS

NOT SOLD SEPARAT

CRANKCASE

1шт.

2

NSS

NOT SOLD SEPARAT

CRANKSHAFT

1шт.

3

NSS

NOT SOLD SEPARAT

PISTONS

1шт.

4

NSS

NOT SOLD SEPARAT

CONNECTING RODS

1шт.

5

NSS

NOT SOLD SEPARAT

CAMSHAFT

1шт.

6

NSS

NOT SOLD SEPARAT

TAPPETS

1шт.

7

NSS

NOT SOLD SEPARAT

FRONT PLATE

1шт.

8

NSS

NOT SOLD SEPARAT

CAMSHAFT GEAR

1шт.

9

NSS

NOT SOLD SEPARAT

CRANKSHAFT GEAR

1шт.

10

NSS

NOT SOLD SEPARAT

OIL PUMP AND INLET CONNECTIONS

1шт.

11

NSS

NOT SOLD SEPARAT

CYLINDER HEAD

1шт.

12

NSS

NOT SOLD SEPARAT

VALVES

1шт.

13

NSS

NOT SOLD SEPARAT

ROCKER ARMS

1шт.

14

NSS

NOT SOLD SEPARAT

PUSH RODS

1шт.

15

NSS

NOT SOLD SEPARAT

VALVE COVERS

1шт.

16

NSS

NOT SOLD SEPARAT

FRONT COVER

1шт.

17

NSS

NOT SOLD SEPARAT

OIL PAN

1шт.

18

NSS

NOT SOLD SEPARAT

OIL PRESSURE REGULATOR VALVE

1шт.

19

NSS

NOT SOLD SEPARAT

OIL COOLER

1шт.

20

NSS

NOT SOLD SEPARAT

COOLANT THERMOSTAT AND HOUSING

1шт.

21

NSS

NOT SOLD SEPARAT

OIL FILTER BASE

1шт.

684289C92

SKELETON ENGINE, new, Consists of Ref. 22 - 27

1шт.

22

NSS

NOT SOLD SEPARAT

CAMSHAFT

1шт.

23

NSS

NOT SOLD SEPARAT

CONNECTING RODS AND BEARING

1шт.

24

NSS

NOT SOLD SEPARAT

CRANKCASE

1шт.

25

NSS

NOT SOLD SEPARAT

CRANKSHAFT AND BEARINGS

1шт.

26

NSS

NOT SOLD SEPARAT

PISTONS, PINS AND RINGS

1шт.

27

NSS

NOT SOLD SEPARAT

VALVE TAPPETS

1шт.

749271C92

ENGINE, EXCHANGE

SKELETON ENGINE, renewed, Consists of Ref. 28 - 33

1шт.

28

NSS

NOT SOLD SEPARAT

CAMSHAFT

1шт.

29

NSS

NOT SOLD SEPARAT

CONNECTING RODS AND BEARINGS

1шт.

30

NSS

NOT SOLD SEPARAT

CRANKCASE

1шт.

31

NSS

NOT SOLD SEPARAT

CRANSHAFT AND BEARINGS

1шт.

32

NSS

NOT SOLD SEPARAT

PISTONS, pins and rings

1шт.

33

NSS

NOT SOLD SEPARAT

VALVE TAPPETS

1шт.

684194C92

STRIPPER PACKAGE

PACKAGE, crankcase gasket, Consists of Ref. 34 - 63

1шт.

34

671964C1

GASKET

air compressor

1шт.

35

673133C1

GASKET

crankcase front plate

1шт.

36

304573R1

GASKET

cranking motor

1шт.

37

341269R2

GASKET

flywheel housing

1шт.

38

671052C1

GASKET

front cover

1шт.

39

601877C1

GASKET

hydraulic pump hole cover

1шт.

40

682111C1

GASKET

injection pump adapter cover

1шт.

41

672302C1

GASKET

oil cooler rear

1шт.

42

612053C1

GASKET

oil cooler, filter end

1шт.

43

672099C2

GASKET

oil cooler tube

1шт.

44

612056C2

GASKET

oil cooler, Serial Range: tube-flange

1шт.

45

328911R1

GASKET

oil filter header

1шт.

46

345246R1

GASKET

oil inlet elbow

1шт.

47

337204R3

OIL PAN GASKET SET

oil pan

1шт.

48

3405H

GASKET

oil pan plug

1шт.

49

349065R1

GASKET

oil pump cover

1шт.

50

607130C2

GASKET

oil pump inlet tube

1шт.

51

332303R1

SEAL

oil seal retainer

1шт.

52

601836C2

GASKET

water pump

1шт.

53

446839C1

GASKET

LIQUID GASKET, 5 ounce tube

1шт.

54

570828R1

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1/2 OD tube

2шт.

55

343396R2

SEALING RING

O-RING, 1.09 x 1.387 x .139

3шт.

56

343398R2

RING

O-RING, 1.234 x 1.1512 x .139

2шт.

57

22421R1

O-RING,0.139" Thk x 8.484" ID, -268, Cl 5, 75 Duro

8-1/2 x 8-3/4 x 1/8

1шт.

58

3046999R1

O-RING,0.139" Thk x 4.484" ID, -246, Cl 5, 75 Duro

water pump housing

1шт.

59

684193C91

STRIPPER PACKAGE

PACKAGE, cylinder sleeve ring

8шт.

60

685158C1

SLEEVE

tube

8шт.

61

340092R1

WASHER

WASHER, 13/32 nylon

8шт.

62

687331C1

SEAL

SLEEVE AND FERRULE

1шт.

63

687333C1

THRUST RING

SEAL

1шт.

684195C91

STRIPPER PACKAGE

PACKAGE, cylinder head gasket, Consists of Ref. 64 - 79

1шт.

64

675886C1

GASKET

center exhaust manifold

2шт.

65

671080C1

GASKET

cylinder head

2шт.

66

671084C1

GASKET

cylinder head cover

2шт.

67

671082C1

GASKET

end cover

4шт.

68

675887C1

GASKET

exhaust flange

2шт.

69

671957C1

GASKET

filter mounting adapter

1шт.

70

675885C1

GASKET

front and rer exhaust manifold

4шт.

71

673992C1

GASKET

intake manifold

2шт.

72

601076C1

WASHER,9.42mm ID x 17.27mm OD x 1.68mm Thk

GASKET, nozzle

8шт.

73

618560C1

GASKET

oil inlet tube flange

1шт.

74

671956C1

GASKET

thermostat elbow

1шт.

75

670355C1

GASKET

turbo oil drain flange

1шт.

76

670354C1

GASKET

turbocharger

1шт.

77

673156C1

GREASE

MOLYKOTE, tube of, GN

1шт.

78

364879R1

O-RING,0.103" Thk x 0.862" ID, -118, Cl 5, 75 Duro

7/8 x 1-1/16 x 3/32

8шт.

79

685158C1

SLEEVE

tube

8шт.

684193C91

STRIPPER PACKAGE

PACKAGE, cylinder sleeve ring, Consists of Ref. 80

8шт.

80

NSS

NOT SOLD SEPARAT

RINGS (NSS)

3шт.

687161C91

PACKING

PACKAGE, water pump seal, Consists of Ref. 81

1шт.

81

NSS

NOT SOLD SEPARAT

SEAL (NSS)

1шт.

82

NSS

NOT SOLD SEPARAT

SEAT (NSS)

1шт.
