Запчасти Case IH DV-550 (A-03) - SKELETON SERVICE ENGINE / SERVICE PACKAGES

1

479661C91

SKELETON SERVICE ENGINE, Replaces 434447C91 and 467004C91, Consists of: Ref. 2 - 8

1шт.

2

NSS

NOT SOLD SEPARAT

CAMSHAFT

1шт.

3

NSS

NOT SOLD SEPARAT

CONNECTING RODS AND BEARINGS

1шт.

4

NSS

NOT SOLD SEPARAT

CRANKCASE

1шт.

5

NSS

NOT SOLD SEPARAT

CRANKSHAFT AND BEARINGS

1шт.

6

NSS

NOT SOLD SEPARAT

OIL PUMP, less screen

1шт.

7

NSS

NOT SOLD SEPARAT

PISTONS, PINS AND RINGS

1шт.

8

NSS

NOT SOLD SEPARAT

VALVE TAPPETS

1шт.

9

315663C96

GASKET

SET, engine upper, Used only on engines with one piece tapped cover, Consists of: Ref. 10 - 24

1шт.

10

258168C1

GASKET

water outlet

2шт.

11

295465C3

GASKET

air cleaner to intake manifold

2шт.

12

259117C3

MANIFOLD GASKET

exhaust manifold

8шт.

13

259105C1

GASKET

intake manifold

2шт.

14

259057C1

GASKET

cylinder head cover

2шт.

15

488844C2

GASKET

cylinder head

2шт.

16

269740C1

GASKET, injection, Serial Range: pump-adapter

1шт.

17

111024R1

SEAL

valve stem

16шт.

18

364879R1

O-RING,0.103" Thk x 0.862" ID, -118, Cl 5, 75 Duro

nozzle

8шт.

19

383317C1

GASKET

nozzle

8шт.

20

293739R1

O-RING,0.139" Thk x 1.359" ID, -220, Cl 5, 75 Duro

water crossover

4шт.

21

310959R1

O-RING,-217, 70 Duro, 1.171" ID x .139" Thk

compressor bracket

1шт.

22

298967C2

GASKET

compressor

1шт.

23

345273C2

GASKET

compressor

1шт.

24

317066C3

GASKET

tappet cover

1шт.

25

484822C92

SEAL PACKAGE

GASKET SET, engine upper, Used only on engines with two piece tappet cover, Consists of: Ref. 26 - 40

1шт.

26

1701207C1

GASKET

water outlet

2шт.

27

295465C3

GASKET

air cleaner to intake manifold

2шт.

28

259117C3

MANIFOLD GASKET

exhaust manifold

8шт.

29

259105C1

GASKET

intake manifold

2шт.

30

259057C1

GASKET

cylinder head cover

2шт.

31

476158C2

GASKET

cylinder head

2шт.

32

269740C1

GASKET, injection, Serial Range: pump-adapter

1шт.

33

111024R1

SEAL

valve stem

16шт.

34

364879R1

O-RING,0.103" Thk x 0.862" ID, -118, Cl 5, 75 Duro

7/8 x 1-1/16 class 5, nozzle

8шт.

35

383317C1

GASKET

nozzle

8шт.

36

293739R1

O-RING,0.139" Thk x 1.359" ID, -220, Cl 5, 75 Duro

1-3/8 x 1-5/8 class 5, water crossover

4шт.

37

298967C2

GASKET

compressor

1шт.

38

345273C2

GASKET

compressor

1шт.

39

133577R4

GASKET

crankcase tapped cover

2шт.

40

310959R1

O-RING,-217, 70 Duro, 1.171" ID x .139" Thk

1-3/16 x 1-7/16 class 5, compressor mounting bracket

1шт.

41

315664C94

POCKET

PACKAGE, crankcase and front cover overhaul gasket, Consists of: Ref. 42 - 60

1шт.

42

348714C2

GASKET

front, Serial Range: cover-crankcase

1шт.

43

448428C1

RING

GASKET, oil pan

1шт.

44

312836C2

GASKET, oil filter and cooler, Serial Range: base-crankcase

1шт.

45

298629C1

GASKET

water pump body to front cover

1шт.

46

1701264C1

GASKET

pump body to water pump bearing housing

1шт.

47

1701207C1

GASKET

water outlet

3шт.

48

259085C1

GASKET

injection pump adapter to front cover

1шт.

49

258174C1

GASKET

water pump outlet to front cover

1шт.

50

263327C2

GASKET

water outlet

1шт.

51

128868H

GASKET

fuel pump

1шт.

52

293739R1

O-RING,0.139" Thk x 1.359" ID, -220, Cl 5, 75 Duro

water crossover

4шт.

53

258173C1

GASKET

, Serial Range: crossover-block

1шт.

54

312833C1

GASKET, oil cooler, Serial Range: cover-plate

1шт.

55

312834C2

GASKET

oil, Serial Range: cooler-base

1шт.

56

317491C1

GASKET, water outlet

2шт.

57

258122C2

SEAL

rear bearing cap

2шт.

58

348713C1

GASKET

water outlet

1шт.

59

448427C1

GASKET

oil filter and cooler, Serial Range: base-crankcase

1шт.

60

105456

GASKET,Copper, 7/8" x 1 1/8"

annular 7/8 cooler and filter base

2шт.
