Запчасти Case IH D-358 (05-17) - THERMOSTAT, COOLANT MANIFOLD

1

3059669R1

MANIFOLD

COOLANT

1шт.

179817

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5, Full Thd

- S/N XXX Up

8шт.

425-115

NUT,5/16"-24, G5

Up to S/N XXX

8шт.

103320

LOCK WASHER,5/16"

Up to S/N XXX

8шт.

3055221R1

STUD

UP TO S/N XXX

8шт.

2

3055306R1

GASKET

6шт.

3

3136506R1

RING

PACKING

1шт.

4

755023R91

STRAP

CLAMP

4шт.

5

3059673R1

HOSE,42 mm ID x 50.00 mm

1шт.

6

3059672R1

GASKET

1шт.

7

3059676R91

THERMOSTAT

1шт.

8

3055574R1

WASHER,8.5mm ID x 19mm OD x 2.5mm Thk

7шт.

9

3059675R1

HOSE

923, 933

1шт.

9

3218311R1

HOSE

943, 935HD

1шт.

10

3059670R1

HOUSING

THERMOSTAT- 923, 933

1шт.

10

3218582R1

HOUSING

THERMOSTAT- 943, 953HD

1шт.

179817

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5, Full Thd

- S/N XXX Up

4шт.

425-115

NUT,5/16"-24, G5

Up to S/N XXX

4шт.

103320

LOCK WASHER,5/16"

Up to S/N XXX

4шт.

3055221R1

STUD

UP TO S/N XX

4шт.

11

444667

PLUG

1/2

1шт.

12

3144520R1

PLUG

1/4

1шт.

13

3059671R2

ELBOW

HOUSING, THERMOSTAT

1шт.

179847

BOLT,Hex, 3/8" - 16 x 2", Gr 5

2шт.

103321

LOCK WASHER,3/8"

2шт.

Q1597

WASHER

2шт.

14

3132681R1

SHIELD

HEAT PROTECTION

1шт.

15

933223R1

PLUG,Hex, M18 x 1.5

M18 - 943, 953HD

1шт.

16

3051337R1

SEALING RING,M18 x 24mm OD x 1.5mm Thk

1шт.

17

444661

PLUG

3/8

2шт.

18

712616R1

PLUG,Hex, M14 x 1.5

1шт.

19

933610R1

SEALING RING,M14 x 18 x 1.8

Packing

1шт.

20

3136766R2

SEALING WASHER

1шт.

21

3055246R1

GASKET

1шт.

22

3136764R1

HOUSING

CHANNEL, WATER - 923

1шт.

22

3136765R1

CHANNEL

WATER - 933, 943, 953HD

1шт.

179818

BOLT,Hex, 5/16" - 18 x 1", Gr 5

3шт.

179826

BOLT,Hex, 5/16" - 18 x 2", Gr 5

1шт.

426444

BOLT,Hex, 5/16" - 18 x 3 1/4", Gr 5

5/16 X 83 MM

2шт.

103320

LOCK WASHER,5/16"

2шт.

9635082

NUT,5/16" - 18, Gr 5

3шт.

3218395R1

BELLEVILLE WASHER,8.199mm ID x 16mm OD x 0.9mm Thk

(5/16")

4шт.
