Запчасти Case IH D-282 (2-114) - LUBRICATING OIL FILTER, 615 COMBINES AND 656 TRACTORS / ENGINE OIL COOLER

674085C91

RESERVOIR, HYDRAULIC

FILTER ASSEMBLY - lubricating oil, Includes: Ref. 1 - 9, no longer available, order components

1шт.

1

A184775

ENGINE OIL FILTER

ELEMENT - oil filter (Replaces element 675616C91)

1шт.

2

NSS

NOT SOLD SEPARAT

ADAPTER - spin-on oil filter, order kit 538837R91

1шт.

3

304854R1

RING

GASKET - oil filter adapter

1шт.

4

NSS

NOT SOLD SEPARAT

BOLT - filter base adapter, order kit 538837R91

1шт.

5

601789C11

BASE

- oil filter, no longer available

1шт.

5a

217-436

PLUG,Hex Soc, 3/8" - 18 NPTF

- oil filter, hex socket, 3/8 inch PT, not shown

1шт.

6

221-841

PLUG

- hex socket, 1/4 inch PT, drain (Replaces plug 444618)

1шт.

7

534180R1

VALVE

- oil filter base (Replaces valve 384528R2)

1шт.

8

384527R1

SPRING

- element by-pass

1шт.

9

100-21100

SNAP RING,1.00", Int, #100

Ring, Snap, (Replaces ring 303322R1) 1.00", Int, #100

1шт.

10

601790C2

GASKET

- oil filter base

1шт.

138225

BEARING

SCREW - hex, 5/16 NC x 1-3/4 inch, no longer used

2шт.

413-720

BOLT,Hex, 7/16" - 14 x 1-1/4", Gr 5

- hex, 7/16 NC x 1-1/4 inch (Replaces bolt 179860)

3шт.

413-732

BOLT,Hex, 7/16" - 14 x 2", Gr 5

- hex, 7/16 NC x 2 inch (Replaces bolt 179866)

1шт.

492-11044

LOCK WASHER,7/16"

WASHER, LOCK, (Replaces washer 103322) 7/16"

4шт.

538837R91

KIT

- spin-on oil filter conversion, Includes: Ref. 2 - 4

1шт.

11

320182R1

CONNECTOR - water inlet hose, no longer available

1шт.

12

320275R1

ELBOW UNION

ELBOW - hose, 90 degree, 5/8 x 1/2 NPT

1шт.

13

214-1410

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

CLAMP, HOSE, , Adjustable, Water hose #10, 0.56/1.06 Type F Worm

4шт.

14

321880R1

HOSE

- water inlet, used with 403 combines, 416 and 422 cotton pickers

1шт.

14

321878R1

HOSE

- water inlet, used with 615 combines, 656 and 706 tractors

1шт.

15

279212R92

COOLER

ASSEMBLY - engine oil, no longer available, order components

1шт.

15

1810274C91

COOLER

ASSEMBLY - engine oil, no longer available, order components (Replaces cooler 338905R91)

1шт.

3228132R1

COOLER

- oil

1шт.

349038R2

MANIFOLD GASKET

- oil cooler

1шт.

1810276C1

SPACER

- oil cooler

1шт.

113-336

BOLT,Hex, 7/16" - 14 x 2-1/4", Gr 5

- hex, 7/16 NC x 2-1/4 inch

1шт.

61-33132

HEX SOC SCREW,5/16"-18 x 2"

BOLT - hex socket, 5/16 NC x 2 inch

1шт.

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC (Replaces nut 102634)

4шт.

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, (Replaces washer 103320) 5/16"

4шт.

16

238-5210

O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro

Oil cooler to manifold -210, 70 Duro, .734" ID x .139" Thk

2шт.

17

349038R2

MANIFOLD GASKET

- oil cooler manifold (Replaces gasket 349038R1)

1шт.

279160R11

MANIFOLD ASSEMBLY - engine oil cooler, Includes: Ref. 18 - 22

1шт.

18

251400R1

VALVE

- oil cooler relief

1шт.

19

279163R1

SPRING

- oil cooler relief valve

1шт.

20

251403R1

GASKET

- relief valve plug

1шт.

21

251402R1

PLUG

- relief valve

1шт.

22

NSS

NOT SOLD SEPARAT

MANIFOLD - oil cooler, order manifold assembly 279160R11

1шт.

444574

PLUG,Sq Hd, 1/4"-18 NPTF

- square head pipe, 1/4 inch, no longer used

2шт.

23

312503R1

PIPE CLAMP

HOSE - water outlet, 403 combines, 416 and 422 cotton pickers

1шт.

23

305206R1

HOSE

- water outlet, used with 656 and 706 tractors

1шт.

23

337393R1

HOSE

- water outlet, used with 615 combines, 42 inch (107 mm) long, cut from bulk hose 364359C1

1шт.

364359C1

HOSE

- bulk, 50 foot (15240 mm) long

1шт.
