Запчасти Case IH D-268 (05-22) - COOLANT FILTER

Схема запчастей Case IH D-268 - (05-22) - COOLANT FILTER
5
6
3
13
16
9
4
14
12
11
5
17
7
10
15
1
8
2
9

Артикул

Название

Примечание

Количество

1

3230134R2

ADAPTER

ON UNITS W/CAB

1шт.

2

3142785R1

TEE

ON UNITS WITH CAB

1шт.

2

3233280R1

TEE,M12

ON UNITS WITH CAB: TIMMERMAN

1шт.

2

3401357R1

UNION

XL-VERSION

1шт.

3

444034

REDUCER,1/2"-14 NPTF x 3/8"-18 Fem NPTF

ON UNITS WITHOUT CABS

1шт.

4

3228212R93

PIPE

1шт.

5

606618C1

ELBOW UNION

Union Elbow 3/8 X 5/8 - 743: UP TO S/N 731102 - 745S: UP TO S/N 568595 - 844S: UP TO 032240

1шт.

6

3233208R1

UNION

1шт.

6

3233345R1

UNION

ON UNITS WITH CAB: TIMMERMAN

1шт.

7

3233341R91

TUBE

ON UNITS WITH CAB: FRITZMEIER/ SEKURA

1шт.

7

3401930R1

PIPE

(XL VERSION)

1шт.

7

3233344R91

TUBE

ON UNITS WITH CAB: TIMMERMAN

1шт.

8

3233340R92

TUBE

ON UNITS WITHOUT CAB

1шт.

8

TUBE, HEATER UNIT - XL VERSION - SEE PARTS CATALOG 1091859R1

1шт.

9

690191C1

COCK, DRAIN

TAP, WATER

2шт.

10

3228211R1

SUPPORT

1шт.

138243

PIN

3/8 X 32 MM

4шт.

103321

LOCK WASHER,3/8"

4шт.

11

427446C1

HEAD

COVER

1шт.

12

690171C1

FILTER

1шт.

13

3228269R1

CONNECTOR, ELEC

CONNECTOR HOSE : SEKURA - 844S

1шт.

14

930241R1

BANJO BOLT,M16 x 1.5 x 36mm

HOLLOW M16 743 : S/N 731103 UP - 745S: S/N 568596 UP - 844S: S/N 032241 UP

1шт.

14

930241R1

BANJO BOLT,M16 x 1.5 x 36mm

HOLLOW M16 - XL-VERSION

1шт.

15

933155R1

SEALING RING,M16 x 20 x 1.5

743 : S/N 731103 UP - 745S: S/N 568596 UP - 844S: 032241 -

2шт.

15

933155R1

SEALING RING,M16 x 20 x 1.5

(XL-VERSION)

2шт.

16

25534R1

WASHER

2шт.

17

3228188R1

STUD

2шт.

103026

NUT,3/8"-24, G5

2шт.

Выбрано товаров: 28
