Запчасти Case IH BD-144 (A-21) - INJECTION NOZZLE, ENGINE SERIAL NUMBER 17289 AND ABOVE

1

3040870R91

FUEL SYSTEM INJECTOR

NOZZLE AND NOZZLE HOLDER ASSY., injection, Order nozzle, 3040870R94, (2) Washers, 706077R1, (2) Washers, 703519R1 and Stud, 705498R1, Consists of

2шт.

706275R91

NOZZLE HOLDER

BODY

1шт.

706289R1

BOLT

1шт.

706290R1

CAP

1шт.

706292R1

NUT

1шт.

706288R1

NUT

1шт.

706283R1

NUT

1шт.

3040871R91

NOZZLE CAP

NOZZLE

1шт.

706282R91

NEEDLE BEARING CAGE

SPINDLE

1шт.

706293R1

SPRING

1шт.

706287R1

WASHER

2шт.

703519R1

WASHER

2шт.

706291R1

WASHER

2шт.

1

3040870R93

FUEL SYSTEM INJECTOR

NOZZLE AND NOZZLE HOLDER ASSY., injection, Order nozzle, 3040870R94, (2) Washers, 706077R1, (2) Washers, 703519R1 and Stud, 705498R1, Consists of

4шт.

3066622R91

BODY

1шт.

706289R1

BOLT

1шт.

3066624R1

CAP

1шт.

3066623R1

NUT

1шт.

3066627R1

NUT

1шт.

3040871R91

NOZZLE CAP

NOZZLE

1шт.

706282R91

NEEDLE BEARING CAGE

SPINDLE

1шт.

3066625R1

SPRING

1шт.

706287R1

WASHER

2шт.

703519R1

WASHER

1шт.

706291R2

SEALING WASHER,14.5mm ID x 21mm OD x 1.42mm Thk

1шт.

3066626R1

WASHER

1шт.

1

3040870R94

NOZZLE CAP

NOZZLE AND NOZZLE HOLDER ASSY., injection, Consists of

4шт.

3105347R1

BODY

1шт.

895579H1

CAP

1шт.

3105346R1

NUT

1шт.

3105349R1

NUT

1шт.

3105348R1

SPINDLE

1шт.

3066625R1

SPRING

1шт.

895578H1

WASHER

1шт.

895581H1

WASHER

1шт.

3040871R91

NOZZLE CAP

NOZZLE

1шт.

103026

NUT,3/8"-24, G5

8шт.

706077R1

WASHER

8шт.

3107104R1

WASHER

4шт.

3107105R1

WASHER

4шт.

2

706288R1

NUT

nozzle holder cap, Used w/3040870R91

4шт.

2

3066623R1

NUT

nozzle holder cap, Used w/3040870R93

4шт.

2

3105349R1

NUT

nozzle holder cap, Used w/3040870R94

4шт.

3

706287R1

WASHER

joint, Used w/3040870R91 and 3040870R93

8шт.

3

895581H1

WASHER

Used w/3040870R94

4шт.

4

706292R1

NUT, Used w/3040870R91

4шт.

5

706290R1

CAP, spring, Used w/3040870R91

1шт.

5

3066624R1

CAP, spring, Used w/3040879R93

1шт.

5

895579H1

CAP, spring, Used w/3040870R94

1шт.

6

895578H1

WASHER

shim, Used w/3040870R94

1шт.

7

706293R1

SPRING

Used w/3040870R91

1шт.

7

3066625R1

SPRING

Used w/3040870R93 and 3040870R94

1шт.

8

706282R91

NEEDLE BEARING CAGE

SPINDLE ASSY., Used w/3040870R91 and 3040870R93

1шт.

8

3105348R1

SPINDLE ASSY., Used w/3040870R94

1шт.

9

706275R91

NOZZLE HOLDER

BODY ASSY., Used w/3040870R91

1шт.

9

3066622R91

BODY

ASSY., Used w/3040870R93

1шт.

9

3105347R91

BODY

ASSY., Used w/3040870R94

1шт.

10

3040871R91

NOZZLE CAP

NOZZLE ASSY.

1шт.

11

706283R1

NUT

nozzle cap, Used w/3040870R91

1шт.

11

3066627R1

NUT

nozzle cap, Used w/3040870R93

1шт.

11

3105346R1

NUT

nozzle cap, Used w/3040870R94

1шт.

12

706291R2

SEALING WASHER,14.5mm ID x 21mm OD x 1.42mm Thk

4шт.

13

708314R1

CHAMBER

HOLDER, pre-combustion chamber

1шт.

14

710382R3

GASKET,29mm ID x 35mm OD x 1.22mm Thk

pre-combustion chamber upper

4шт.

15

3045523R1

CHAMBER

pre-combustion

1шт.

16

710383R1

GASKET

pre-combustion chamber lower

4шт.
