Запчасти Case IH 330 TRUE-TANDEM (75.200.31) - SCRAPER KIT BETWEEN GANGS 34 FOOT (75) - SOIL PREPARATION

1

84232143

SCRAPER BLADE

Extension Right

3шт.

2

84232149

SCRAPER BLADE

Extention Left

3шт.

3

84226988

SCRAPER BLADE

Double Wide Extention

2шт.

4

84229417

SPACER

Extension Scraper

2шт.

5

280508

CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 1/4", Gr 5

6шт.

6

9707516

BOLT,1/2"-13 x 1-3/4", Cl 5

2шт.

7

9706716

BOLT,Hex, 1/2" - 13 x 2", Gr 5

2шт.

8

9602228

CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 3/4", Gr 5

2шт.

9

85700693

NUT,5/8" - 11, Gr C

8шт.

10

86992215

LOCK NUT,1/2"-13, GC

4шт.

11

84228545

DIA KIT, HARVESTER

Scraper Betwwen Gangs 34 foot Incl 1 - 10 Instruction Sheet 84228548

1шт.
