Артикул
Название
Примечание
Количество
1
149950C91
CYLINDER
4.25 x 8 master, refer to cyl - 1 for components
2шт.
1252009C1
KIT
o-ring & cyl
1шт.
810751C1
PIN
cyl mounting headed
4шт.
432-1624
COTTER PIN,1/4" x 1 1/2"
Pin, Split (Cotter), 1/4" x 1 1/2"
4шт.
1277593C91
ROD
SCREW ASSY, L
2шт.
124829
JAM NUT,Hex, 3/8" - 16, Gr 5
2шт.
2
587639R1
HYD CONNECTOR,9/16"-18, 37 Degree x 3/4"-18, O-Ring
CONNECTOR, C-Z hyd fld 1/2 to 3/8 sht, replaces 481352R1
2шт.
3
1284269C1
HYDRAULIC HOSE
HOSE, front tractor hyd 3/8 x 360 in. long, replaces hose, 810491C1 (70 in. long) hose, 810593C1 (292 in. long) & fitting 9402787, for service replacement of hoses also furnish
2шт.
9403528
TUBE NUT,37 Degree, 3/4"-16, Type B
NUT, 1/2 C-Z hyd fld tube style B
2шт.
9403400
REDUCER,37 Degree, 1/2" x 3/8" Tube
FITTING, 1/2 x 3/8 C-Z hyd fld tube redr
2шт.
4
9402981
SHAFT
3/8 C-Z hyd flared three way, replaces 9402982
2шт.
5
812381C2
HYDRAULIC HOSE
HOSE, master cylinder pressure LH 3/8 x 115 in. long, replaces 810597C1, for service replacement also furnish
1шт.
9403528
TUBE NUT,37 Degree, 3/4"-16, Type B
NUT, 1/2 C-Z hyd fld tube style B
2шт.
9403400
REDUCER,37 Degree, 1/2" x 3/8" Tube
FITTING, 1/2 x 3/8 C-Z hyd fld tube redr
2шт.
6
810139C2
HYDRAULIC HOSE,9.53mm ID x 1397mm L, SAE 100R7
HOSE, master cyl pressure RH 3/8 x 55 in. long, replaces 810599C1 for service replacement also furnish
1шт.
9403528
TUBE NUT,37 Degree, 3/4"-16, Type B
NUT, 1/2 C-Z hyd fld tube style B
2шт.
9403400
REDUCER,37 Degree, 1/2" x 3/8" Tube
FITTING, 1/2 x 3/8 C-Z hyd fld tube redr
2шт.
7
935036R91
ELBOW
C-Z hyd fld adj 1/2 to 3/8 90D, replaces 9410977
8шт.
9
587639R1
HYD CONNECTOR,9/16"-18, 37 Degree x 3/4"-18, O-Ring
CONNECTOR, C-Z hyd fld 1/2 to 3/8 sht, replaces 9410203
2шт.
10
1284298C1
HYDRAULIC HOSE
HOSE, slave cyl pressure 3/8 x 160 in. long
2шт.
11
1284267C1
HOSE
return LH 3/8 x 335 in. long replaces hose, 810594C1 (249 in. long) hose, 810598C2 (89 in. long) & fitting 9402787, for service replacement also furnish
1шт.
9403528
TUBE NUT,37 Degree, 3/4"-16, Type B
NUT, 1/2 C-Z hyd fld tube style B
2шт.
9403400
REDUCER,37 Degree, 1/2" x 3/8" Tube
FITTING, 1/2 x 3/8 C-Z hyd fld tube redr
2шт.
12
1284261C1
HOSE
return Rh 3/8 x 250 in. long, replaces hose, 810595C2 (183 in. long) hose, 810598C1 (98 in. long) & fitting 9402787, for service replacement also furnish
1шт.
9403528
TUBE NUT,37 Degree, 3/4"-16, Type B
NUT, 1/2 C-Z hyd fld tube style B
2шт.
9403400
REDUCER,37 Degree, 1/2" x 3/8" Tube
FITTING, 1/2 x 3/8 C-Z hyd fld tube redr
2шт.
13
1272485C92
CYLINDER ASSY.
CYLINDER, 4 x 8 slave, refer to cyl - 1 for components, replaces 810642C91 & 149980C91
2шт.
13
87423777R
REMAN-HYD CYLINDER
Reman for New PN 1272485C92
2шт.
13
87423777C
CORE-HYD CYLINDER
Return Number
2шт.
80117C2
SEAL KIT
o-ring & seal
1шт.
810751C1
PIN
cyl mounting headed
4шт.
432-1624
COTTER PIN,1/4" x 1 1/2"
Pin, Split (Cotter), 1/4" x 1 1/2"
4шт.
14
813006C2
HYDRAULIC HOSE
HOSE, wing lift extension 3/8 x 85 in. long, replaces 810598C1, for service replacement also furnish
2шт.
9403528
TUBE NUT,37 Degree, 3/4"-16, Type B
NUT, 1/2 C-Z hyd fld tube style B
2шт.
9403400
REDUCER,37 Degree, 1/2" x 3/8" Tube
FITTING, 1/2 x 3/8 C-Z hyd fld tube redr
2шт.
15
1282328C92
CYLINDER ASSY.
CYLINDER, 3.75 x 8 slave, refer to cyl - 1 for components, replaces 810643C91 & 149969C91
2шт.
15
87423766R
REMAN-HYD CYLINDER
CYLINDER, 3.75 x 8 slave, refer to cyl - 1 for components, replaces 810643C91 & 149969C91
2шт.
15
87423766C
CORE-HYD CYLINDER
Return Number
2шт.
80115C2
SEAL KIT
KIT, o-ring & seal
1шт.
810751C1
PIN
cyl mounting headed
4шт.
432-1624
COTTER PIN,1/4" x 1 1/2"
Pin, Split (Cotter), 1/4" x 1 1/2"
4шт.
813579C1
CABLE TIE
STRAP, hose tie, HV
10шт.
306132C1
CABLE TIE,14.5" L
STRAP, hose tie
8шт.
299406C1
CLAMP,7/16", Insul, 3/8" Bolt
.438 dia znp coated med clo
8шт.
495967R1
CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd
BOLT, 3/8 x 1 crg type 5
8шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
8шт.
120377
NUT,3/8" - 16, Gr 5
8шт.
Выбрано товаров: 48
