Запчасти Case IH RMX370 (55.404.03) - 37 FOOT LIGHT PARTS (55) - ELECTRICAL SYSTEMS

1

84161908

WIRE HARNESS

Front, Not Shown

1шт.

2

84141928

WIRE HARNESS

Rear, Not Shown

1шт.

3

87520382

LIGHT

Red, Rh

1шт.

3

87519398

LIGHT

Red, Lh

1шт.

4

87519394

LIGHT,12V, 21W, Amber

Amber

2шт.

5

87716

BOLT,1/4"-20 x 1-1/4", Cl 5

16шт.

5

230-4244

LOCK NUT,1/4"-20, GA

16шт.

6

86992211

NUT

1/4, NC

20шт.

7

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

2шт.

8

27601214

HOLDER

Seven Pin Connector Storage, Not Shown

1шт.

9

533959R1

CABLE TIE,.135" x 11"

CABLE STRAP Not Shown

1шт.

10

386170C1

CABLE TIE,.30" x 27 1/2"

CABLE STRAP Black, Not Shown

1шт.

11

84207339

FRAME

Crossbar

1шт.

12

311863A1

REFLECTOR

Flourescent

1шт.

13

311865A1

REFLECTOR

Red

1шт.

14

84207340

FRAME

Lh

1шт.

14

84207341

FRAME

Rh

1шт.

15

311864A1

REFLECTOR

Yellow

1шт.

16

311863A1

REFLECTOR

Flourescent

1шт.

17

311865A1

REFLECTOR

Red

1шт.

18

409848A1

U-BOLT,5/8" - 11 x 127.80mm W x 107.81mm L, Spcl

BOLT "U" 5/8 x 5 x 4-1/4

2шт.

19

86992216

NUT

5/8, Stover

4шт.

20

86992215

LOCK NUT,1/2"-13, GC

Stover

4шт.

23

413-844

BOLT,Hex, 1/2" - 13 x 2-3/4", Gr 5

4шт.

24

413-420

BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5

16шт.
